Southbend (Middleby)

Southbend Outdoor Countertop Gas Charbroiler, 24-Inch, 4 Burners, 80,000 BTU, 316L Stainless Steel

SKU: HDC-24-316L
$5,286.00
/each
Free Shipping
Expected delivery date of ,
if ordered within hours and minutes
Not Shipping to ?
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

Related Searches

Best Sellers Charbroilers Charbroilers & Grills Commercial Grills New Arrivals Outdoor Commercial Grills Restaurant Equipment Southbend (Middleby)

Southbend Outdoor Countertop Gas Charbroiler, 24-Inch, 4 Burners, 80,000 BTU, 316L Stainless Steel

Stainless Steel Radiants, Rod Grates, 5-Inch Splash Guards, and Grease Drawer

Built for durable outdoor grilling, this 24-inch countertop charbroiler pairs 316L stainless steel construction with 80,000 BTU of output across four burners.

  • 24-inch outdoor countertop charbroiler for compact commercial grilling applications.
  • Four burners deliver 80,000 BTU total for strong, even heat.
  • 316L stainless steel construction, radiants, and splash guards improve durability.
  • Grease drawer, 4-inch grease trough, and full-width crumb tray simplify cleanup.
  • Available for natural gas or propane with a rear gas connection and included regulator.

Overall Dimensions:

24.0"W x 33.25"D x 16.13"H

Product Weight:

240.0 lb

Outdoor Countertop Design

Compact charbroiler built for outdoor counterline use on a countertop.

316L Stainless Steel Construction

Front, rear, sides, and bottom panels are made of 316L stainless steel for corrosion resistance.

4 High-Output Burners

Four burners provide a total of 80,000 BTU for fast, responsive heat.

Stainless Steel Radiants

316L stainless steel radiants help distribute heat evenly across the cooking surface.

Rod Cooking Grates

6-inch-wide, 3/8-inch round rod grates provide a durable cooking surface.

5-Inch Splash Guards

Rear and side splash guards help contain grease and splatter.

Grease Management System

Includes a grease drawer, 4-inch grease trough, and full-width crumb tray for easier cleanup.

Independent Burner Controls

Each straight burner has its own gas valve, with a standing pilot serving each burner.

Rear Gas Connection

3/4-inch rear gas connection includes a pressure regulator.

Adjustable Legs

4-inch adjustable legs help level the unit during installation.

Type Charbroiler
Style Outdoor
Installation Type Countertop
Material 316L Stainless Steel
Finish Stainless Steel
Grate Construction Stainless Steel Rod Grates
Burner Quantity 4
BTU 80,000 BTU
Gas Connection Size 3/4 Inch Rear Male NPT
Gas Inlet Pressure 7 Inches W.C. Natural Gas / 11 Inches W.C. Propane
Shipping Width 24 Inches
Shipping Depth 34 Inches
Shipping Height 17 Inches
Shipping Weight 240 lb.
Country of Origin USA
Selling Unit Each
Units Per Case 1

Certifications & Compliance

Certified badge of NSF Certified
NSF Certified
Certified badge of CSA Certified
CSA Certified

Warranty & Protection

1-year parts and 1-year labor limited warranty.

Documents

PDF Cutsheet PDF Download PDF Middleby financial flyer PDF Download PDF Warranty sheet PDF Download

Frequently Asked Questions

The unit measures 24 inches wide, 33.25 inches deep, and 16.13 inches high.
It is available for natural gas or propane. Minimum supply pressure is 7 inches W.C. for natural gas and 11 inches W.C. for propane.
The HDC-24-316L provides 80,000 BTU total.
It is intended for use in non-combustible locations only and should be installed under a vented hood.
The unit includes a one-year limited warranty for parts and labor from the date of original purchase.
