Southbend (Middleby) 4721DD-3GL Ultimate Gas Ranges
Description
Southbend Ultimate 72" Gas Restaurant Range – 6 Open Burners, 36" Left-Side Griddle & Dual Standard Ovens
Model 4721DD • Total Input: 352,000 BTUEngineered for high-volume commercial kitchens, the Southbend Ultimate Series 4721DD combines raw cooking power with the rugged build quality chefs have trusted since 1898. Six lifetime-clog-free burners, a full 36-inch griddle and two porcelain-lined ovens give you a complete cookline in just six feet of space.
Key Features
- (6) patented non-clog cast-iron burners, 33,000 BTU each (standing pilots).
- 1/2" thick cold-rolled steel griddle (left), 36" wide, 64,000 BTU.
- (2) Standard ovens, 45,000 BTU each, battery-spark ignition & snap-action thermostats 175-550 °F.
- Fully porcelain-enameled oven cavities (14"H × 26"W × 26.5"D) – fits full-size sheet pans both directions; one rack supplied per oven.
- 27" deep cooking surface with two removable drip trays for easy cleanup.
- 22 1/2" flue riser with heavy-duty storage shelf – perfect for smallwares or plating.
- Front-mounted gas shut-off valves (one for each side) and factory-installed regulator.
- Stainless steel front, sides, 4" front rail & shelf; 6" adjustable stainless legs.
- cCSAus, CSA Flame, CSA Star & NSF certified for gas safety and sanitation.
- 1-year limited parts & labor warranty backed by Southbend’s nationwide service network.
Performance Specifications
| Overall width | 73 in (1854 mm) |
|---|---|
| Overall depth | 34 in (864 mm) |
| Cook-top height | 37 in (940 mm) |
| Flue height (with shelf) | 59 1/2 in (1511 mm) |
| Total input | 352,000 BTU/hr |
| Open burners | 6 × 33,000 BTU (198,000 BTU) |
| Griddle | 36" plate, 64,000 BTU |
| Ovens | 2 × 45,000 BTU (standard) |
| Gas connection | 3/4" NPT (rear) |
| Minimum inlet pressure | 7" W.C. Natural | 11" W.C. LP |
| Crated weight | ≈ 1,075 lb (488 kg) |
Why Choose Southbend’s Ultimate Series?
- Lifetime-clog-free burners reduce maintenance and downtime.
- Cast-iron grates support up to 14" stock pots and can be lifted off for deep cleaning.
- Heavy-gauge stainless & fully welded frame survive daily abuse in the busiest kitchens.
- Front-facing controls keep cooks safely away from hot flue gases.
- Field-configurable for natural gas or propane.
To prevent front-rail overheating, limit oversized cookware (>12" Ø) to the rear burners. Install on 6" legs or casters over a non-combustible floor and place under a properly vented hood.
