Southbend (Middleby) 4721DD-3CL Ultimate Gas Ranges
Description
Southbend “Ultimate” 72" Restaurant Range
6 Non-Clog Burners • 36" Left-Side Charbroiler • Twin Standard OvensBuilt for high-volume kitchens that demand power, flexibility and rugged reliability, the Southbend Ultimate 472-series range (build ID 7706) puts 384,000 BTU of cooking performance in one 72" footprint. From sauté and stock production to finishing steaks on a true charbroiler, everything you need is under one hood.
Performance & Convenience
- (6) patented 33,000 BTU non-clog cast-iron burners—lifetime clog-free design handles even the heaviest stock pots.
- Integrated 36" radiant charbroiler (left) with removable cast-iron grates, 96,000 BTU and standing pilots—perfect for steaks, chops and menu-marking.
- (2) full-size standard ovens (45,000 BTU ea.) with battery-spark ignition; porcelain interiors fit 18" × 26" sheet pans front-to-back or side-to-side. One rack per cavity included.
- 27"-deep cooking surface with four extra-wide cast-iron grates—rear sections support stock pots up to 14".
- 22-1/2" flue riser & heavy-duty staging shelf keep plates and smallwares within easy reach.
- Front-mounted manual gas shut-off valves (one per battery side) for fast service isolation.
- All-stainless exterior (front, sides & shelf) and removable drip trays for fast cleanup.
- (6) 6" stainless adjustable legs standard; optional heavy-duty casters available.
Quick Specs
| Overall width | 73" (1854 mm) |
|---|---|
| Overall depth | 34" (864 mm) |
| Cook-top height | 37" (940 mm) |
| Cooking power | 384,000 BTU/hr (natural gas) |
| Open burners | 6 × 33,000 BTU non-clog |
| Charbroiler | 36" radiant, 96,000 BTU (left-side) |
| Ovens (2) | Standard, 45,000 BTU each; 175 – 550 °F thermostat |
| Gas inlet | 3/4" NPT (factory regulator supplied) |
| Ignition | Standing pilots (top & broiler) / battery spark (ovens) |
| Listings | CSA, NSF |
| Warranty | 1-year parts & labor (U.S./Canada commercial use) |
What’s in the Box
- (1) Ultimate 72" range as configured above
- (2) Oven racks (1 per cavity)
- Factory pressure regulator & 22-1/2" flue riser shelf
- Installation & operation manual
Need casters, quick-disconnect hose or salamander broiler? Ask our team about Southbend factory options.
