Southbend (middleby)

Southbend (middleby) 4721aa-3gl ultimate gas ranges

SKU: 4721AA-3GL
$22,105.00
/each
Discontinued
Want to speak to an expert?

Southbend Ultimate 72" Gas Restaurant Range – 6 Non-Clog Burners, 36" Griddle & Double Convection Ovens

Model 472 Series | 326,000 BTU | Natural / LP

Combine the fire-power of six patented non-clog burners, a thick 36-inch steel griddle, and two high-performance convection ovens—all in one 72-inch footprint. Built on Southbend’s legendary Ultimate platform, this range is engineered to thrive on the busiest cook lines while making change-over from sauté to bake to grill effortless.

Key Performance Features

  • (6) 33,000 BTU lifetime-clog-free cast-iron burners with standing pilots.
  • Left-side 36" griddle with a ½" cold-rolled steel plate for even heat retention.
  • (2) 32,000 BTU convection ovens with 5-speed rack guides & 3 chrome racks each.
  • Front-mounted manual gas shut-off valves—one for each half of the range.
  • Battery-spark ignition for oven bases; no external electrical ignition required.
  • 27"-deep cooktop accommodates up to 14" stock pots on rear grates.
  • 22 ½" flue riser with heavy-duty stainless storage shelf keeps plates & utensils handy.
  • 4" stainless front rail, stainless front/sides, and porcelain-enameled oven interiors for superior cleanability.
  • cCSAus, CSA Flame & Star, and NSF certified for commercial kitchens.

Technical Specifications

Overall Width 72 ⅞" (73")
Overall Depth 34"
Cooking Surface Height 37"
Cooktop Layout (6) non-clog burners + 36" griddle (left)
Oven Type Dual convection, 175 – 550 °F thermostat
Total Gas Input 326,000 BTU/hr
Gas Connection ¾" NPT (rear), 7" WC NG / 11" WC LP minimum inlet
Electrical (fans) 115 V / 5.9 A, 6' cord & NEMA 5-15P
Construction Stainless front, sides & shelf; spring-assisted doors; 6" adjustable SS legs
Included Items 3 racks per oven, factory pressure regulator
Warranty 1-year parts & labor, factory authorized service nationwide

Looking for a different burner-to-griddle ratio, charbroiler top, or casters? Reach out—Southbend’s Ultimate line is fully configurable.

Commercial installation required: Unit must be set under a vent hood and leveled on 6" legs or casters. Avoid placing oversized (12"+) cookware on the front rail to prevent heat damage.

Overall Dimensions:

73.0"W x 41.8"D x 59.5"H

Product Weight:

1320.0 lb
Manufacturer Southbend (Middleby)
Brand name Ultimate
Certifications ["NSF", "cCSAus", "CSA Star", "CSA Flame"]
Height 59.5in
Width 73.0in
Depth 41.8in
Shipping Weight 1320.0lbs
Exterior Finish stainless steel front & sides
Base (2) convection ovens
Vent backriser with hi-shelf
Top (6) open burners, (1) 36" griddle
Plate Thickness .500" = 1/2"
Specifications Ultimate Restaurant Range, gas, 72", (6) non-clog burners, (1) 36" griddle left, standing pilot, (2) convection ovens with battery spark ignition, includes (3) racks per oven, 22-1/2" flue riser with shelf, stainless steel front, sides & shelf, 6" adjustable legs, 326,000 BTU, cCSAus, CSA Flame, CSA Star, NSF
