Southbend (Middleby) 4607DC-2GR Ultimate Gas Ranges
Description
Southbend Ultimate 60" Gas Restaurant Range
4 Pyromax Burners | 24" Right-Hand Griddle | Standard Oven & Cabinet BaseBuilt for kitchens that never slow down, the Southbend Ultimate Series packs 253,000 BTU of raw, reliable power into a space-saving 60-inch footprint. From high-heat stir-fry to all-day baking, this range delivers the versatility, durability and cooking precision professional chefs demand.
Highlights
- 4 Pyromax™ burners (40,000 BTU each) – patented, three-piece, non-clog design with built-in drip ring.
- 24" right-side griddle – ½" polished steel plate with raised splash sides for a consistent sear and easy cleanup.
- 45,000 BTU standard oven – battery-spark ignition, 175-550 °F thermostat, porcelain-enameled interior and one heavy-duty rack.
- Left-hand cabinet base – stainless storage compartment keeps hotel pans, sheet pans or smallwares within reach.
- 22½" flue riser with integrated shelf – perfect for plates, spices or finishing sauces.
- 4" deep stainless front rail and two removable drip trays for a cleaner work station.
- Front-mounted manual gas shut-off and factory-installed regulator simplify installation and daily operation.
- 6" adjustable stainless legs make leveling on uneven floors quick and tool-free.
- One-piece stainless front, sides and shelf resist corrosion and wipe down fast at the end of service.
Firepower & Efficiency
- Total input: 253,000 BTU/hr – ready to tackle peak-hour volume without breaking a sweat.
- Rear Pyromax burners accept stock pots up to 14" for high-capacity boiling or sauces.
- Standing pilots on open burners keep starts instant; oven uses battery spark to conserve energy.
Certifications
- cCSAus
- CSA Flame
- CSA Star
- NSF Listed – meets the latest sanitation standards.
Technical Specs
| Model | Ultimate 60" Restaurant Range (Pyromax/Griddle/Oven/Cabinet) |
|---|---|
| Overall Dimensions (W × D × H) | 60.75" × 34" × 59.5" (to top of flue shelf) |
| Cooking Surface Height | 37" |
| Burners | 4 Pyromax, 40,000 BTU each |
| Griddle | 24" wide × 27" deep, 48,000 BTU, manual control |
| Oven | Standard bake, 45,000 BTU, 1 rack / 2 positions |
| Gas Connection | ¾" NPT (female) – regulator supplied |
| Required Inlet Pressure | Nat Gas 7" W.C. / LP 11" W.C. |
| Legs | 6" stainless, adjustable |
| Total Input | 253,000 BTU/hr |
| Warranty | 1-year parts & labor (see Southbend limited warranty for details) |
Oversized cookware (12"+ diameter) should be used on the rear burners to avoid heat damage to the front rail.
