Southbend (Middleby) 4607AC-2GR Ultimate Gas Ranges
Description
Ultimate 60" Gas Restaurant Range – Pyromax/Griddle/Convection
Southbend (Middleby) • Model AC • 240,000 BTU • NSF, cCSAus, CSA Flame & StarGive your kitchen the fire-power chefs crave and the versatility operators demand. Southbend’s Ultimate Series packs four high-output Pyromax burners, a full 24" right-hand griddle, a true convection oven, and a spacious stainless cabinet into one rock-solid, 60-inch footprint. From rapid boil to delicate sauté, from all-day pancakes to perfectly even baking, this range does it all—without slowing you down.
Why You’ll Love It
- 4 Pyromax burners (40,000 BTU ea.) – patented three-piece, non-clog design with built-in drip ring for easy cleanup and maximum heat transfer.
- 24" smooth steel griddle (½" polished plate) on the right—ideal for breakfast, burgers & more.
- Convection oven base (32,000 BTU) with battery-spark ignition, 175 °F–550 °F thermostat, 3 chrome racks & 5 positions for full-size sheet pans.
- Stainless cabinet base on the griddle side keeps hotel pans, utensils or dry goods close at hand.
- Heavy-duty 22½" flue riser & overshelf for safe venting and extra plate-up space.
- One-piece 4" front rail, removable cast-iron top grates (rear holds 14" stock pots), and front-mounted manual gas shut-off.
- Battery spark ignition on the oven—no electrical outlet required for open burners.
- 6" stainless steel adjustable legs (casters optional) for fast leveling and under-range cleaning.
- Factory-installed ¾" regulator plus cCSAus, CSA Flame & Star, and NSF certifications.
- 1-year parts & labor warranty backed by Southbend’s nationwide service network.
At-a-Glance Specs
| Overall width | 60 ¾ in. |
|---|---|
| Overall depth | 42 ⅛ in. (with convection base) |
| Cooking surface height | 37 in. |
| Open burners | 4 Pyromax • 40,000 BTU each |
| Griddle plate | 24 in. W × 27 in. D • ½" polished steel |
| Oven type / capacity | Gas convection • 14 H × 26 W × 24 D in. interior (fits full-size pans length- or width-wise) |
| Oven BTU / temp range | 32,000 BTU • 175 °F – 550 °F |
| Secondary base | Stainless steel cabinet with center-opening doors (included) |
| Total input | ≈ 240,000 BTU/hr (natural or LP—specify) |
| Gas connection | ¾" NPT female (rear, factory-regulated) |
| Electrical | 115 V plug, 5.9 A (convection blower only) |
| Certifications | NSF, cCSAus, CSA Flame, CSA Star |
| Warranty | 1 year parts & labor (see Southbend limited warranty for details) |
Gas ranges must be installed under a properly sized vent hood, with 7" W.C. minimum (Nat) / 11" W.C. minimum (LP) inlet pressure. If mounting on flooring other than quarry tile, consult factory for approved leg or curb options.
