Southbend (Middleby) 4606DC-2GR Ultimate Gas Ranges
Description
Southbend Ultimate 60" Gas Restaurant Range
3 Star/Sauté Burners • 2 Pyromax Burners • 24" Right-Side Griddle • Standard Oven & Cabinet BasePower, versatility and durability—packed into one rugged range. The Southbend Ultimate 60" combines rapid-reaction open burners, a high-output griddle and a full-size oven, giving chefs the freedom to sauté, sear, simmer and bake from a single station.
Key Performance Features
- (3) 33,000 BTU cast-iron star/saute burners in front for fast, even pan heat.
- (2) 40,000 BTU patented Pyromax burners in back—perfect for woks or stock pots.
- 24" x 27" right-side griddle with ½" polished steel plate (64,000 BTU) for all-day searing and breakfast service.
- 45,000 BTU standard oven with battery-spark ignition—no external power needed.
- Stainless steel cabinet base keeps sheet pans, utensils or dry goods right where you need them.
- Front-mounted manual gas shut-off and factory-installed pressure regulator for safe, code-compliant installs.
- Heavy-gauge stainless front, sides & 4" rail plus 6" adjustable legs for a rock-solid stance on any line.
- Removable cast-iron grates and full-width drip trays cut daily clean-up time.
- 22 ½" flue riser with integrated plate shelf adds prep/storage space without increasing footprint.
At-a-Glance Specifications
| Manufacturer / Series | Southbend – Ultimate 60" Series |
|---|---|
| Configuration | (3) star/saute front burners, (2) Pyromax rear burners, 24" right-side griddle, 1 standard oven, 1 cabinet base |
| Total Input | 272,000 BTU/hr (natural gas) |
| Oven Temp Range | 175 °F – 550 °F (79 °C – 288 °C) |
| Oven Interior | 14" H x 26" W x 26.5" D • (1) rack, 2 positions |
| Griddle Plate | 24" W x 27" D, ½" smooth steel, manual controls |
| Cooking-Surface Height | 37" |
| Overall Dimensions | 60.75" W x 34" D x 59.5" H (to top of flue) |
| Gas Connection | ¾" NPT female • Min. inlet 7" W.C. (natural) |
| Construction | Stainless steel front, sides, shelf & rail • 6" adjustable stainless legs |
| Ignition | Standing pilots (top) • Battery spark (oven) |
| Certifications | cCSAus, CSA Flame, CSA Star, NSF |
| Warranty | 1-year limited parts & labor |
What’s Included
- Factory-installed pressure regulator
- (1) heavy-duty oven rack
- 22 ½" flue riser with shelf
- 6" adjustable stainless legs
