Southbend (Middleby) 4605CC-2GR Ultimate Gas Ranges
$11,321.00
Unit price
/
Unavailable
Description
Southbend “Ultimate” 60″ Gas Restaurant Range
Model 460 – 3 Open Burners / 2 Pyromax Burners / 24″ Right-Side Griddle / Dual CabinetsPack maximum productivity into only five feet of line space. Southbend’s Ultimate series gives you 227,000 BTU of searing power, a polished 24″ griddle, and heavy-duty storage cabinets – all wrapped in easy-to-clean stainless steel.
Why This Range Rocks
- Combination top for any menu mix: 3 × 33,000 BTU non-clog burners up front, 2 × 40,000 BTU Pyromax burners in back for stock-pots & woks, plus a 48,000 BTU 24″ griddle on the right-hand side.
- One-piece, lifetime-clog-free cast-iron burner design with removable cast-iron grate tops (rear grate accepts up to a 14″ stock pot).
- Full 27″-deep cooking surface and a 4″ deep stainless front rail for plating and pans.
- 22-½″ flue riser with integrated heavy-duty shelf – perfect for warming plates or holding smallwares.
- Two spacious, stainless steel cabinet bases for sheet pans, hotel pans, or dry goods (optional doors available at no charge).
- Front-mounted manual shut-off valve and factory-installed gas pressure regulator for quick, code-compliant installation.
- 6″ adjustable stainless legs (casters optional) allow easy leveling and under-range cleaning.
- cCSAus, CSA Flame, CSA Star & NSF listed for worry-free code compliance.
Performance & Utility
| Total Input | 227,000 BTU/hr (Natural Gas) |
|---|---|
| Open Burners | 3 × 33,000 BTU non-clog |
| High-Output Burners | 2 × 40,000 BTU Pyromax |
| Griddle Plate | 24″ w × 1/2″ polished steel, 48,000 BTU manual control |
| Gas Connection | ¾″ NPT female (right- or left-side depending on griddle location) |
| Required Gas Pressure | Natural Gas – 7″ W.C. (Propane – 11″ W.C.) |
Dimensions
| Overall Width | 60.75″ (1543 mm) |
|---|---|
| Overall Depth | 34.00″ (864 mm) |
| Cook-Surface Height | 37.00″ (940 mm) |
| Height to Top of Flue | 59.50″ (1511 mm) |
| Shipping Weight | Approx. 1,075 lb (488 kg) |
Warranty
Covered by Southbend’s 1-year parts & labor warranty. Full terms available at southbendnc.com/service-and-parts.
Commercial Use Only: Oversized cookware (≥ 12″ Ø) should be kept on rear grates to avoid excessive front-rail heat.
Never block burners or grates with sheet pans during cleaning.
Features & Specs
Features & Specs
Manufacturer
Southbend (Middleby)
Brand_name
Ultimate
Certifications
NSF, cCSAus, CSA Star, CSA Flame
Height
59.5in
Width
60.75in
Depth
34.0in
Shipping Weight
1075.0lbs
Base
(2) cabinets
Top
(5) open burners, (1) 24" griddle
Vent
backriser with hi-shelf
Exterior Finish
stainless steel front & sides
Plate Thickness
.500" = 1/2"
Specifications
Ultimate Restaurant Range, gas, 60", (3) non-clog burners front, (2) pyromax burners rear, (1) 24" griddle right, (2) cabinets, 22-1/2" flue riser with shelf, stainless steel front, sides, shelf & 6" adjustable legs, 227,000 BTU, cCSAus, CSA Flame, CSA Star, NSF
