Southbend (Middleby) 4604DC-2GR Ultimate Gas Ranges
$11,518.00
Unit price
/
Unavailable
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options
Southbend (Middleby) 4604DC-2GR Ultimate Gas Ranges is backordered and will ship as soon as it is back in stock.
Documents
Related Searches
Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.
Southbend (Middleby) 4604DC-2GR Ultimate Gas Ranges
$11,518.00
Unit price
/
Unavailable
Description
Southbend “Ultimate” 60" Gas Restaurant Range
3 Star/Sauté Burners • 3 Non-Clog Burners • 24" Right-Side Griddle • Standard Oven & Cabinet BaseWhen your line never stops, you need a range that can keep up. Southbend’s Ultimate Series delivers 291,000 BTU of reliable, even heat in a rugged all-stainless package that’s built to thrive in the toughest commercial kitchens.
Why You’ll Love It
- Six high-performance open burners – front (3) 33 K BTU star/sauté for lightning-fast pan work, rear (3) 33 K BTU lifetime non-clog cast-iron for stock pots up to 14".
- 24" right-side griddle – ½" polished steel plate (48 K BTU) with raised sides for all-day searing, browning and breakfast service.
- Standard oven base – 45 K BTU, 175 – 550 °F thermostat, battery-spark ignition, porcelain enamel interior, spring-assisted door & (1) rack with two positions.
- Integrated cabinet base – keeps hotel pans, sheet pans and utensils right where you need them.
- 4" deep stainless front rail plus 22½" flue riser with heavy-duty plate shelf for warming or staging.
- Front-mounted manual gas shut-off, factory regulator and standing pilots for simple, safe operation.
- All-stainless exterior (front, sides, rail & shelf) on 6" adjustable legs for years of easy-clean, rock-solid service.
- Certified cCSAus, CSA Flame, CSA Star & NSF.
- Backed by a 1-year limited parts & labor warranty.
At-a-Glance Specs
| Manufacturer / Series | Southbend – Ultimate Restaurant Range |
|---|---|
| Model Configuration | 3 Star (front) + 3 Non-Clog (rear) burners, 24" R-hand griddle, standard oven & cabinet base |
| Total Input | 291,000 BTU/hr (Natural Gas) |
| Cooktop Width × Depth | 60.75" W × 27" D cooking surface (34" overall depth) |
| Cooking Height | 37" to cook surface |
| Height w/ Flue Riser | 59.5" |
| Oven Interior | 26" W × 26.5" D × 14" H – porcelain enamel |
| Griddle Plate | 24" W × 27" D, ½" thick polished steel |
| Gas Connection | ¾" NPT (female), factory regulator supplied Inlet pressure: 7" WC NAT / 11" WC LP |
| Electrical | None required – battery spark ignition (oven) |
| Certifications | cCSAus, CSA-Flame, CSA-Star, NSF |
| Warranty | 1 year parts & labor (see details below) |
What’s Included
- Ultimate 60" gas range (as configured above)
- 22.5" flue riser with overshelf
- (1) oven rack
- Factory-installed gas pressure regulator
- 6" adjustable stainless legs
- Owner’s / installation manual
Popular Accessories (sold separately)
- Swivel casters (front locking)
- Quick-disconnect gas hose kits
- Additional oven racks
- Center-opening doors for cabinet base
- Salamander or cheesemelter mounting kits
Important:
• This appliance is intended for commercial use under a properly vented hood.
• For non-quarry tile floors, consult the factory for approved installation methods.
• Oversized cookware (12"+ diameter) should be used on rear burners only to prevent excessive front-rail heat.
• Do not cover griddle or burners with sheet pans during cleaning – damage is not covered under warranty.
• This appliance is intended for commercial use under a properly vented hood.
• For non-quarry tile floors, consult the factory for approved installation methods.
• Oversized cookware (12"+ diameter) should be used on rear burners only to prevent excessive front-rail heat.
• Do not cover griddle or burners with sheet pans during cleaning – damage is not covered under warranty.
Complete warranty terms are available at southbendnc.com/service-and-parts.
Features & Specs
Features & Specs
Manufacturer
Southbend (Middleby)
Brand_name
Ultimate
Certifications
NSF, cCSAus, CSA Star, CSA Flame
Height
59.5in
Width
60.75in
Depth
34.0in
Shipping Weight
1075.0lbs
Plate Thickness
.500" = 1/2"
Vent
backriser with hi-shelf
Exterior Finish
stainless steel front & sides
Top
(6) open burners, (1) 24" griddle
Base
(1) standard oven, (1) cabinet
Specifications
Ultimate Restaurant Range, gas, 60", (3) star/sauté burners front, (3) non-clog burners rear, (1) 24" griddle right, standing pilot, (1) standard oven with battery spark ignition, (1) cabinet base, includes (1) rack, 22-1/2" flue riser with shelf, stainless steel front, sides, shelf & 6" adjustable legs, 291,000 BTU, cCSAus, CSA Flame, CSA Star, NSF
