Southbend (Middleby) 4604CC-4TR Ultimate Gas Ranges
Description
Southbend Ultimate 60" Gas Restaurant Range – 48" Thermostatic Griddle & Two Open Burners
Model #: Ultimate 460 Series | 146,000 BTU | cCSAus, CSA Flame & Star, NSFBuilt to thrive on the busiest cooklines, the Southbend Ultimate 60" Restaurant Range pairs a full-size 48" thermostatic griddle with two high-performance open burners and spacious stainless cabinet storage. Get the legendary durability chefs count on—plus the flexibility to sear, sauté, grill and stage all from one powerhouse platform.
Key Performance Features
- 48" smooth, 1" thick polished steel griddle (right-side) with thermostatic controls for precise zone-to-zone temperature management.
- Two open top burners (front 33 k BTU star/sauté & rear 33 k BTU non-clog) accept up to 14" stock pots; standing pilots for instant lighting.
- 4" deep stainless front rail keeps plates & pans within easy reach while protecting controls.
- Dual stainless steel cabinet bases provide quick-grab storage for sheet pans, smallwares and cleaning tools.
- Factory-installed 22.5" flue riser with heavy-duty shelf—perfect for resting finished dishes or warming plates.
- Stainless steel front, sides, shelf and 6" adjustable legs withstand years of high-heat, high-volume service.
- Front-mounted manual gas shut-off for the entire range simplifies daily start-up and end-of-shift safety.
- Battery spark ignition on griddle for reliable, match-free starts (no power cord required).
- Factory regulator included for fast, code-compliant installation.
At-a-Glance Specifications
| Overall width | 60 3⁄4" |
|---|---|
| Overall depth | 34" |
| Cook surface height | 37" |
| Flue riser height | 22 1⁄2" (with integrated shelf) |
| Griddle plate | 48" W × 24" D, 1" polished steel, thermostatic |
| Open burners | (1) 33 k BTU star/sauté (front) | (1) 33 k BTU non-clog (rear) |
| Total input | 146,000 BTU/hr (Natural or LP – field convertible) |
| Gas connection | 3⁄4" NPT (rear) |
| Certifications | cCSAus, CSA Flame, CSA Star, NSF |
| Warranty | 1-year limited parts & labor |
Why Choose Southbend Ultimate?
- One-piece cast‐iron grates and lifetime clog-free burners slash downtime and replacement costs.
- Coved-corner porcelain oven cavities (in oven models) and slide-out crumb trays on ranges speed daily clean-up.
- Modular design lets you add salamanders, cheesemelters or flue riser heights as your menu evolves.
- Backed by Middleby and an extensive North American service network for parts, start-up and maintenance.
