Southbend (Middleby) 4604CC-4GR Ultimate Gas Ranges
Description
Southbend “Ultimate” 60" Gas Restaurant Range
48" Right-Side Griddle • Star/Sauté & Non-Clog Open Burners • Cabinet Base • 146,000 BTUBuilt for kitchens that never slow down, the Southbend Ultimate Series packs rugged construction, precise controls and serious firepower into a single 60-inch footprint. A massive 48-inch griddle handles breakfast to searing steaks, while two versatile open burners on the left keep sauces and sautés right within reach.
Highlights
- 48" smooth steel griddle (right) – 1 inch polished plate with raised splash, manual controls and 80,000 BTU of even heat.
- Dual open-top burners (left) – front 33 kBTU star/sauté burner for rapid, even flame; rear 33 kBTU lifetime non-clog burner accepts up to a 14" stock pot.
- Two full-width stainless cabinets under the griddle/burners keep sheet pans and utensils organized (doors available at no charge).
- 4" deep stainless front rail with convenient front-mounted gas shut-off for the entire range.
- Heavy-gauge stainless front, sides, shelf and 22-1/2" flue riser with utensil shelf withstand the toughest shifts.
- 6" adjustable stainless legs make leveling on uneven floors quick and easy.
- Standing pilots on open burners plus factory regulator (3/4" rear gas connection) for fast start-ups and simple service.
- Certified cCSAus, CSA Flame, CSA Star & NSF — approved for commercial kitchens across North America.
Technical Specs
| Overall Width | 60 3⁄4" (1543 mm) |
|---|---|
| Overall Depth | 34" (864 mm) |
| Working Height | 37" to cooking surface |
| Flue Height | 59 1⁄2" to top of riser shelf |
| Total Input | 146,000 BTU/hr (Natural Gas) |
| Open Burners | 1 × 33 kBTU star/sauté (front) 1 × 33 kBTU non-clog (rear) |
| Griddle Section | 48" W × 24" D plate | 80,000 BTU/hr |
| Gas Inlet | 3/4" NPT (rear), factory preset regulator, 7" W.C. min. inlet pressure |
| Base Configuration | Stainless cabinet left & right (open — door kit optional) |
| Shipping Weight | ≈ 1,075 lb / 488 kg |
| Warranty | 1-year parts & labor, factory-authorized service |
Warranty & Support
Every Ultimate Series range ships with Southbend’s 1-year parts & labor warranty. Service is performed nationwide by factory-authorized technicians for minimal downtime.
- For non-quarry tile flooring, consult the factory for approved leg solutions.
- Limit oversized cookware (12" +) to rear burners to protect front controls.
- Unit is intended for commercial, vent-hood equipped kitchens only.
