Southbend (Middleby) 4604CC-2CR Ultimate Gas Ranges
Description
Ultimate 60" Gas Restaurant Range with 24" Right-Side Charbroiler
Southbend – 262,000 BTU | CSA & NSF ListedBuilt for kitchens that refuse to compromise, the Southbend Ultimate Series delivers the rugged power, versatility, and serviceability that high-volume operations demand. This 60" configuration combines six high-performance open burners with a heavy-duty charbroiler and roomy cabinet bases, giving chefs the freedom to sauté, simmer, sear, and store – all in one rock-solid lineup.
Why This Range Rocks
- Split burner setup – (3) 33 K BTU star/sauté burners up front for fast, even heat & (3) 33 K BTU non-clog burners in back for stock pots or low-simmer work.
- 24" charbroiler (right side) delivers 64 K BTU of flame-kissed grilling power with cast-iron radiants and grates.
- 262,000 BTU total input – all the fire you need to push through the rush.
- Stainless steel construction (front, sides, shelf & 4" front rail) stands up to daily punishment and wipes clean fast.
- 22.5" flue riser with integrated shelf keeps plates, spices or smallwares close at hand.
- Dual cabinet bases offer protected, ventilated storage for sheet pans, utensils, hotel pans and more.
- Removable cast-iron grates handle up to 14" stock pots and lift out for sink-side cleaning.
- Factory-installed ¾" regulator & front-mounted manual gas shut-off streamline installation and service.
- 1-year parts & labor warranty backed by Southbend’s nationwide service network.
Specifications
| Cooking width | 60 3⁄4" (1543 mm) |
|---|---|
| Depth (overall) | 34" (864 mm) |
| Cooking height | 37" (940 mm) to grate surface |
| Open burners | (3) 33 K BTU star/sauté + (3) 33 K BTU non-clog |
| Charbroiler | 24" right-side, 64 K BTU, cast-iron grates |
| Total input | 262 000 BTU/h (Natural or LP – field convertible) |
| Gas connection | ¾" NPT (rear) |
| Base configuration | (2) stainless storage cabinets with adjustable shelves |
| Flue riser | 22 1⁄2" with heavy-duty utensil shelf |
| Legs | 6" stainless, adjustable (casters optional) |
| Certifications | CSA, NSF |
| Warranty | 1-year parts & labor (see Southbend terms) |
Need a custom burner or griddle layout? Ask us about additional Ultimate Series configurations, quick-ship availability, and factory options.
