Southbend (Middleby) 4604AD-4GR Ultimate Gas Ranges

Southbend “Ultimate” 60" Gas Restaurant Range

Built for the busiest commercial kitchens, the Southbend Ultimate Series packs heavy-duty power, precision and versatility into a single 60" footprint. Two open burners, a full 48" griddle and dual oven cavities give chefs the freedom to sauté, sear, bake and roast — all on one rugged, stainless-steel platform that earns CSA and NSF approvals.

Highlights at a Glance

• 60" wide Ultimate Series restaurant range with 27" deep cook top (37" working height).
• Split open-top configuration:
  • 1 × 33,000 BTU Star/Sauté burner (front)
  • 1 × 33,000 BTU Non-clog burner (rear)
• 48" right-hand griddle with 1" polished steel plate  –  80,000 BTU total.
• Dual oven base
  • 45,000 BTU standard oven (battery spark ignition)
  • 32,000 BTU convection oven, 1/2 hp blower, five-position rack guides
• Four chrome racks included (3 convection, 1 standard).
• 22.5" flue riser with integrated stainless utility shelf.
• Front-mounted manual gas shut-off & factory regulator for fast service access.
• Standing pilots for burners; match-free battery spark ignition for both ovens.
• All-stainless front, sides, 4" front rail & shelf with 6" adjustable legs (casters optional).
• Removable cast-iron grate sections accept up to a 14" stock pot; full-width crumb trays speed clean-up.
• cCSAus, CSA Flame, CSA Star & NSF listed for commercial use.
• 1-year limited parts & labor warranty backed by Southbend’s national service network.

Oven Performance

• Temperature range: 175 – 550 °F (79 – 288 °C) on both cavities.
• Porcelain-enamel interiors with coved corners for easy wash-down and even heat.
• Spring-assisted, counter-balanced doors stay open at any angle.
• Convection section includes ON/OFF switch for fan-only baking or holding.

Technical Specifications

* Depth with standard oven only is 34".

Installation Notes

• Operate under an appropriate exhaust hood; minimum rear clearance to combustibles is 0" (10" for charbroiler options).
• 6" adjustable legs supplied; casters and quick-disconnect hose kits available separately.
• Minimum gas supply pressure: 7" W.C. Natural / 11" W.C. Propane.
