Southbend (Middleby) 4604AA Ultimate Gas Ranges
Description
Southbend Ultimate 60" Gas Restaurant Range
Split Top – 5 Star/Sauté Burners (Front) + 5 Non-Clog Burners (Rear) | Double Convection OvensGive your line cooks the firepower they need and your pastry team the consistency they crave. Southbend’s Ultimate Series packs 394,000 BTU of total output into a 60-inch footprint, pairing a flexible split-top burner layout with two full-size convection ovens and a sturdy 22-½" flue riser shelf for extra plating space. Built for heavy-duty, all-day service in high-volume kitchens.
Why you’ll love it
- Blazing heat & control – Five 33,000 BTU star/sauté burners up front for rapid boil-to-simmer moves; five lifetime non-clog 33,000 BTU burners in back for stockpots & sauce work.
- Even-bake convection (x2) with battery-spark ignition, 32,000 BTU each, 175 °F–550 °F range, 3 chrome racks per cavity & 5 position rails.
- One-piece cast-iron grates (removable) hold up to a 14" stockpot on the rear section.
- Front-mounted gas shut-off for the entire range—quick and safe when things get hectic.
- Rugged stainless steel front, sides, shelf & 6" adjustable legs resist corrosion and wipe clean fast.
- 22-½" heavy-duty flue riser shelf adds convenient landing space for pans, spices or plating.
- Battery spark ignition on ovens eliminates the need for an electrical pilot light.
- CSA & NSF listed for worry-free code compliance.
- 1-year parts & labor warranty backed by Southbend’s nationwide service network.
At-a-glance specs
| Model | Ultimate 60" – Split Burner (5 Star / 5 Non-Clog) – 460 AA |
|---|---|
| Total BTU Input | 394,000 BTU (330,000 BTU open top + 64,000 BTU ovens) |
| Burner Configuration | (5) 33 k BTU star/sauté front | (5) 33 k BTU non-clog rear |
| Ovens | (2) convection, 32 k BTU each, 3 racks each, porcelain enamel interior |
| Cooking Surface | 60-3/4" W × 27" D; 37" cook-top height |
| Overall Dimensions | 60-3/4" W × 42-1/8" D × 59-1/2" H (with flue) |
| Gas Connection | 3/4" NPT, Natural Gas 7" W.C. min. inlet pressure |
| Electrical | 115 V / 60 Hz / 1-ph, 5.9 A, factory-installed 6' cord & 3-prong plug |
| Crated Weight | ≈ 1,075 lb |
| Certifications | CSA Flame, CSA Sanitation, NSF |
| Warranty | 1-year limited parts & labor |
What’s included
- Range with split burner top & double convection base
- (10) removable cast-iron grates
- (6) chrome oven racks (3 per cavity)
- Factory-installed pressure regulator
- 22-½" flue riser shelf
- 6" stainless steel adjustable legs
- User & installation manual
Popular add-ons (sold separately)
- All-swivel caster kit with front locks
- Extra oven racks
- Flame-failure safety system (consult factory)
- Shelf & salamander/cheesemelter mounting kits
- Quick-disconnect gas hose (3 ft, 4 ft, 5 ft lengths)
• Use cookware 12" Ø or larger on the rear burners to avoid overheating the front rail.
• Install under a properly sized, vented hood and follow all local codes.
• For non-quarry tile floors, consult Southbend for approved installation methods.
Need peace of mind? Every Ultimate Series range ships with a 1-year parts & labor warranty serviced by Southbend’s nationwide network of authorized technicians.
