Southbend (Middleby) 4603DD-2TR Ultimate Gas Ranges
$13,152.00
Unit price
/
Unavailable
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options
Southbend (Middleby) 4603DD-2TR Ultimate Gas Ranges is backordered and will ship as soon as it is back in stock.
Documents
Related Searches
Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.
Southbend (Middleby) 4603DD-2TR Ultimate Gas Ranges
$13,152.00
Unit price
/
Unavailable
Description
Southbend Ultimate 60″ Gas Restaurant Range – 6 Star Burners, 24″ Right-Side Griddle & (2) Standard Ovens
Model 460DD | 336,000 BTU Total InputEngineered for demanding commercial kitchens, the Ultimate Series packs heavy-duty power and versatility into a single 60-inch footprint. Six high-efficiency star burners share the deck with a precision-controlled 24″ thermostatic griddle, while twin full-size ovens keep pans moving and service flowing.
Key Advantages
- Six 33,000 BTU patented cast-iron star/sauté burners with standing pilots—ideal for high-heat sautéing or stock-pot simmering.
- Right-hand 24″ griddle with ½″ polished steel plate, 4″ splash & 48,000 BTU thermostatic control for consistent zone cooking.
- (2) 45,000 BTU standard ovens (175–550 °F) featuring battery spark ignition, porcelain-enameled cavities & one rack each.
- 22½″ flue riser with heavy-duty shelf keeps utensils, pans and plates within arm’s reach.
- All-stainless front, sides, shelf & 4″ front rail plus 6″ adjustable legs for a rock-solid, level installation.
- Front-mounted manual gas shut-off & factory pressure regulator simplify start-up and servicing.
- Removable cast-iron grate tops (accept up to 14″ stock pots) and deep drip trays streamline nightly cleaning.
- cCSAus, CSA Flame, CSA Star and NSF certified for safety and sanitation.
What’s Included
- Southbend Ultimate 60″ range with 6 burners + 24″ thermostatic griddle (right)
- (2) Standard oven bases with (1) rack each
- 22½″ flue riser & plate shelf
- Factory-installed ¾″ gas pressure regulator & owner’s manual
Technical Specifications
| Total Input | 336,000 BTU/hr |
|---|---|
| Open Burners | 6 × 33,000 BTU star/sauté (standing pilots) |
| Griddle | 24″ right, ½″ plate, thermostatic, 48,000 BTU |
| Ovens | 2 × 45,000 BTU standard; 175–550 °F; battery spark ignition |
| Exterior (W × D × H) | 60.75″ × 34″ × 37″ (to cook top) |
| Flue Riser Height | 22.5″ |
| Oven Interior (each) | 26″ W × 26.5″ D × 14″ H |
| Gas Connection | ¾″ NPT (left side when griddle is on right) |
| Minimum Inlet Pressure | 7″ W.C. Natural | 11″ W.C. LP |
| Crated Weight | Approx. 1,075 lb |
| Warranty | 1-year parts & labor (see Southbend warranty terms) |
| Certifications | cCSAus, CSA Flame, CSA Star, NSF |
Important:
- This appliance is for commercial use only and must be installed under a code-compliant vent hood by a qualified technician.
- If installing on floors other than quarry tile, cement or natural stone, consult Southbend for approved options.
- To avoid excessive heat to the front rail, limit oversized (12″+) cookware to the rear grates.
Ask us about flexible Middleby Equipment Financing to turn your purchase into affordable monthly payments.
Features & Specs
Features & Specs
Manufacturer
Southbend (Middleby)
Brand_name
Ultimate
Certifications
NSF, cCSAus, CSA Star, CSA Flame
Height
59.5in
Width
60.75in
Depth
34.0in
Shipping Weight
1075.0lbs
Top
(6) open burners, (1) 24" griddle with thermostat
Base
(2) standard ovens
Control Type
thermostatic controls
Exterior Finish
stainless steel front & sides
Vent
backriser with hi-shelf
Plate Thickness
.500" = 1/2"
Specifications
Ultimate Restaurant Range, gas, 60", (6) star/sauté burners, (1) 24" griddle right, thermostatic controls, standing pilot, (2) standard ovens with battery spark ignition, includes (1) rack per oven, 22-1/2" flue riser with shelf, stainless steel front, sides, shelf & 6" adjustable legs, 336,000 BTU, cCSAus, CSA Flame, CSA Star, NSF
