Southbend (Middleby)

Southbend Ultimate 60-Inch Gas Restaurant Range with 9 Burners, Standard Oven, and Cabinet Base

SKU: 4603DC-5L
$11,163.00
/each
Free Shipping
Expected delivery date of ,
if ordered within hours and minutes
Not Shipping to ?
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

Related Searches

Best Sellers Commercial Gas Ranges Commercial Ranges Gas Ranges New Arrivals Ranges Restaurant Equipment Southbend (Middleby)

Southbend Ultimate 60-Inch Gas Restaurant Range with 9 Burners, Standard Oven, and Cabinet Base

Standing Pilot, 356,000 BTU, Stainless Steel Exterior

Built for high-volume kitchens, this 60-inch Ultimate gas range combines a powerful 9-burner top, a standard oven, and a cabinet base in one rugged stainless steel station.

  • 9 open burners include 3 non-clog burners on the front left, 2 Pyromax burners on the rear left, and 4 star/sauté burners on the right.
  • One standard oven with battery spark ignition supports baking and roasting.
  • Cabinet base adds practical under-range storage.
  • 22-1/2-inch flue riser with shelf provides extra utility space.
  • Stainless steel front, sides, and shelf are built for durability and easier cleaning.
  • 6-inch adjustable legs help with leveling during installation.
  • 356,000 BTU total output is designed for demanding commercial kitchens.

Overall Dimensions:

60.75"W x 34.0"D x 59.5"H

Product Weight:

1075.0 lb

9-Burner Top

Cooking surface includes 3 non-clog burners on the front left, 2 Pyromax burners on the rear left, and 4 star/sauté burners on the right.

Standard Oven

Includes one standard oven for baking and roasting.

Battery Spark Ignition

The oven is equipped with battery spark ignition for dependable startup.

Cabinet Base

Built-in cabinet base adds under-range storage space.

Standing Pilot

Standing pilot design supports reliable burner operation.

Flue Riser with Shelf

Includes a 22-1/2-inch flue riser with shelf.

Stainless Steel Exterior

Stainless steel front, sides, and shelf improve durability and ease of cleaning.

Adjustable Legs

6-inch adjustable legs help with leveling and installation.

Included Rack

Supplied with one rack for the oven.

High Heat Output

356,000 BTU total output supports heavy-duty cooking demand.

Type Commercial Gas Range
Style Open Burner
Installation Type Floor Model
Controls Standing Pilot
Material Stainless Steel
Finish Stainless Steel
BTU 356,000 BTU
Selling Unit Each
Units Per Case 1
Shipping Width 61 Inches
Shipping Depth 34 Inches
Shipping Height 60 Inches
Shipping Weight 1075 lb.

Certifications & Compliance

Certified badge of NSF Certified
NSF Certified
Certified badge of CSA Certified
CSA Certified

Warranty & Protection

1 year parts and 1 year labor.

Documents

PDF Cutsheet PDF Download PDF Owner's manual PDF Download PDF Middleby financial flyer PDF Download PDF Warranty sheet PDF Download

Frequently Asked Questions

It has 9 open burners: 3 non-clog burners on the front left, 2 Pyromax burners on the rear left, and 4 star/sauté burners on the right.
It includes one standard oven with battery spark ignition and one oven rack.
Yes, it includes one cabinet base.
The range is rated at 356,000 BTU.
The front, sides, and shelf are stainless steel.
