Southbend (Middleby) 4603AD-4TR Ultimate Gas Ranges
Description
Southbend “Ultimate” 60" Gas Restaurant Range
48" Thermostatic Griddle • 2 Star Burners • Standard & Convection Ovens • 223,000 BTUBring powerhouse performance and menu-flexibility to the line with Southbend’s Ultimate Series 60-inch range. A full-width thermostatic griddle, two high-output star burners, and dual ovens (standard + convection) give chefs everything they need in one rugged, stainless-steel workstation.
Key Features
- Massive 223,000 BTU total input for high-volume production
- (2) 33,000 BTU star/sauté burners with lifetime clog-free cast-iron heads & standing pilots
- Right-side 48" × 27" griddle, 1" polished steel plate with thermostatic controls (175 – 550 °F)
- Standard oven (45,000 BTU) + convection oven (32,000 BTU) – both use reliable battery spark ignition
- Four heavy-duty oven racks included (1 in the standard oven, 3 in the convection oven)
- 22-1⁄2" flue riser with heavy-duty shelf keeps plating, pans & seasonings close at hand
- 4" stainless front rail, plus stainless front, sides & shelf for quick wipe-downs and lasting corrosion resistance
- 6" adjustable stainless legs simplify leveling on uneven floors
- Front-mounted manual gas shut-off & factory-installed ¾" pressure regulator
- Certifications: cCSAus, CSA Flame, CSA Star & NSF
Specifications
| Model | 460AD (Ultimate Series) |
|---|---|
| Overall width | 60 3⁄4" / 1543 mm |
| Overall depth | 42 1⁄8" / 1070 mm * (convection base) |
| Cooking surface height | 37" / 940 mm |
| Flue riser height | 22 1⁄2" / 572 mm (with shelf) |
| Open burners | (2) star/sauté, 33,000 BTU each |
| Griddle | 48" W × 27" D, 1" thick plate, thermostatic (175 – 550 °F) |
| Standard oven | 45,000 BTU, 175 – 550 °F, 1 rack |
| Convection oven | 32,000 BTU, 175 – 550 °F, 3 racks, 115 V fan (5.9 A, 6' cord & plug) |
| Total input | 223,000 BTU/hr |
| Gas connection | ¾" NPT (rear), min. 7" W.C. NAT |
| Electrical | 115 V / 60 Hz / 1 Ø (convection fan) |
| Warranty | 1-year parts & labor (commercial use) |
*Depth shown includes convection oven motor housing.
Built for the Long Haul
- Ultimate-grade frame & fully welded chassis stand up to daily abuse
- Coved-corner porcelain ovens eliminate hot spots and speed clean-up
- Removable drip trays & cast-iron grates streamline end-of-shift maintenance
- Modular design pairs perfectly with Southbend salamanders & cheesemelters
