Southbend (Middleby) 4603AA Ultimate Gas Ranges
Description
Southbend Ultimate 60" Gas Restaurant Range – 10 Star/Sauté Burners & Dual Convection Ovens
Natural Gas • 394,000 BTU total • CSA & NSF ListedBuilt for the busiest commercial kitchens, the Southbend Ultimate Series gives chefs the power, versatility, and durability they demand. Ten high-performance star burners deliver even, clog-free flame across the entire 27"-deep cooktop, while twin convection ovens below keep pans of roasted, baked or finished dishes moving at peak service speeds.
Why You’ll Love It
- (10) 33,000 BTU cast-iron star burners – patented one-piece design for lifetime clog-free performance.
- Two 32,000 BTU convection ovens with battery-spark ignition for reliable starts—no electrical hook-up required for the burners.
- Porcelain-enameled oven cavities with coved corners for fast wipe-down and superior heat circulation.
- Each oven ships with 3 adjustable racks (5 positions) to handle full-size sheet pans in either direction.
- 22.5" flue riser with heavy-duty integrated utensil shelf maximizes vertical storage.
- Front-mounted manual gas shut-off plus factory-installed ¾" regulator for quick installation.
- Rugged stainless steel front, sides, 4" front rail & shelf; 6" adjustable stainless legs.
- Standing pilots on open tops for instant, match-free lighting.
- 1-year limited parts & labor warranty backed by Southbend’s nationwide service network.
At-a-Glance Specs
| Width | 60.75" (1543 mm) |
|---|---|
| Depth | 34" (864 mm) |
| Cooking Height | 37" (940 mm) to cooktop |
| Cooktop Configuration | (10) star/saute burners, cast-iron grates |
| Burner Output | 33,000 BTU each |
| Oven Bases | (2) convection, battery-spark ignition |
| Oven Output | 32,000 BTU each |
| Total Input | 394,000 BTU/hr |
| Oven Interior (WxDxH) | 26" × 24" × 14" |
| Racks Supplied | 3 per oven (5 positions) |
| Gas Connection | ¾" NPT (rear), 7" W.C. minimum inlet pressure (Natural) |
| Electrical | 115-V, 5.9 A, 6′ cord & plug (for oven blower motors) |
| Construction | Stainless steel exterior; porcelain oven liners |
| Flue Riser | 22.5" with storage shelf |
| Certifications | CSA, NSF |
| Warranty | 1 year parts & labor |
