Southbend (Middleby) 4602DC-3GR Ultimate Gas Ranges
Description
Southbend Ultimate 60" Gas Restaurant Range
4 Non-Clog Burners | 36" Right-Side Griddle | Standard Oven & Cabinet BaseBuilt for kitchens that run hard from open to close, the Southbend Ultimate Range combines heavy-duty construction with the flexible cooking power chefs demand. From high-heat sauté work to breakfast service on the griddle and reliable baking below, this 60" model delivers it all in one rugged, stainless-steel platform.
Performance & Design Highlights
- 4 27 k BTU lifetime non-clog open burners with wavy cast-iron grates for full-surface pan support.
- 36" right-side griddle – ½" smooth, polished steel plate with raised splash sides; perfect for eggs, burgers & sandwiches.
- 45 k BTU standard oven (175 °F – 550 °F) with battery-spark ignition; includes 1 rack & 2 position rails.
- Left-hand stainless cabinet base keeps sheet pans, smallwares or dry goods within arm’s reach.
- One-piece 4" front rail, front-mounted gas shut-off and factory-installed ¾" regulator for fast installs.
- 22 ½" flue riser with heavy-duty shelf – ideal landing zone for plates, spices or a mounted salamander (optional).
- Standing pilots on open burners for instant lighting; manual controls on griddle for true operator feel.
- Total input: 217,000 BTU/hr | cCSAus, CSA Flame, CSA Star & NSF listed.
Technical Specifications
| Cooking width | 60 ¾" (1543 mm) |
|---|---|
| Depth / Cook-surface height | 34" / 37" |
| Overall height (incl. riser) | ≈ 59 ½" |
| Open burners | 4 × 27 k BTU non-clog, cast iron tops |
| Griddle | 36" W × 27" D, ½" steel plate, 96 k BTU |
| Oven type / capacity | Standard, porcelain interior 14" H × 26" W × 26 ½" D – fits full-size sheet pans either direction |
| Oven input | 45 k BTU, 175 °F – 550 °F thermostat |
| Base (left) | Stainless open cabinet with adjustable shelf (doors optional) |
| Total gas input | 217 k BTU/hr (Natural Gas) |
| Gas connection | ¾" NPT, rear – min. 7" W.C. NG (11" W.C. LP) |
| Shipping weight | ≈ 1,075 lb (488 kg) |
| Certifications | cCSAus, CSA Flame, CSA Star, NSF |
| Warranty | 1-year parts & labor (see Southbend T&C) |
Popular Options & Accessories
- Swivel casters with front locks
- Full-width cabinet doors (no-charge)
- 5" or 10" flue riser
- Extra oven racks
- 3 ft – 5 ft quick-disconnect hose (ANSI Z21.69 compliant)
- Salamander or cheesemelter mounts
This appliance is intended for commercial use only and must be installed under an appropriate vent hood by a qualified technician.
