Southbend (Middleby) 4602CC-2TR Ultimate Gas Ranges
Description
Southbend Ultimate 60" Gas Restaurant Range – 6 Burners + 24" Right-Side Griddle
Item #7706 • 210,000 BTU • NSF, cCSAus, CSA Flame & StarBuilt to dominate high-volume service, the Ultimate Series combines Southbend’s legendary durability with serious cooking horsepower. This 60" model pairs six patented non-clog cast-iron burners with a full-size, thermostatically-controlled griddle—giving chefs the speed and flexibility to run an entire line from one rugged platform.
Performance Highlights
- Six (6) 27,000 BTU non-clog cast-iron burners for a lifetime of even, reliable flame.
- Heavy wavy cast-iron grates create a continuous surface and cradle round-bottom cookware.
- 24" right-hand griddle with ½" polished steel plate and precision thermostatic controls.
- Front-mounted master gas shut-off valve plus standing pilots on open tops for instant ignition.
- 22½" flue riser with heavy-duty plate-warming shelf keeps finished dishes within reach.
- Dual stainless cabinet bases store sheet pans, stock pots and smallwares; doors available at no charge.
- 4" deep stainless front rail protects controls and doubles as a plating ledge.
- 6" adjustable stainless steel legs for easy leveling and cleaning underneath.
- Factory-installed ¾" gas pressure regulator included.
Specifications
| Overall width | 60.75" (1543 mm) |
|---|---|
| Overall depth | 34" (864 mm) |
| Cooking-top height | 37" (940 mm) |
| Open burners | 6 × 27,000 BTU non-clog (162,000 BTU total) |
| Griddle section | 24" right-side • 48,000 BTU • ½" smooth plate • thermostatic |
| Total input | ≈ 210,000 BTU/hr |
| Gas connection | ¾" NPT (min. inlet: 7" W.C. NG • 11" W.C. LP) |
| Base configuration | Two stainless storage cabinets |
| Exterior construction | Stainless front, sides, shelf & rail |
| Certifications | NSF • cCSAus • CSA Flame • CSA Star |
| Warranty | 1-year parts & labor |
Looking for a different burner or griddle layout? Ultimate Series ranges can be factory-configured to match almost any menu.
Why Operators Choose Ultimate
- Patented burner & grate system resists clogging and maximizes heat transfer, lowering maintenance costs.
- Single piece of equipment replaces separate hot line stations, saving valuable hood space.
- Backed by Middleby’s nationwide parts & service network.
- Proudly manufactured in Fuquay-Varina, North Carolina, USA.
Power, precision, and rock-solid reliability—upgrade your kitchen with the Southbend Ultimate Range and keep the tickets moving shift after shift.
