Southbend (Middleby) 4602AC-4GR Ultimate Gas Ranges
Description
Ultimate 60" Gas Restaurant Range – 48" Right-Side Griddle & Convection Oven
Southbend | Model 460AC • SKU 7706 • 166,000 BTUCrafted for the busiest commercial kitchens, Southbend’s Ultimate 60" Range unites two clog-free open burners, a massive 48" griddle and a high-performance convection oven in one rock-solid stainless-steel platform. Consistent results, easy cleaning and legendary durability come standard.
Key Features & Benefits
- 2 Non-Clog Open Burners (27,000 BTU ea.) – one-piece cast-iron design resists grease build-up and delivers an even flame every time.
- Wavy Cast-Iron Grates – “bowl” profile improves pan stability & heat transfer and lets you slide stock pots anywhere on the range top.
- 48" Right-Side Griddle – 1" thick polished steel plate distributes heat evenly for perfect sears, pancakes or burgers; raised side splashes keep the mess contained.
- 32,000 BTU Convection Oven – battery spark ignition, 3 heavy-duty racks, 5 position rails and a porcelain interior for fast, even baking and simple wipe-down.
- Stainless Cabinet Base – full-width storage for sheet pans, smallwares or cleaning supplies.
- 22½" Flue Riser with Heavy-Duty Shelf – warms plates and keeps spices or utensils within reach.
- Front-Mounted Master Gas Shut-Off – cut fuel to the entire range instantly for service or safety.
- Factory-Installed Regulator + Standing Pilots – rapid start-up and reliable operation with no external parts to lose.
- 6" Stainless Adjustable Legs – level the unit on uneven floors or upgrade to casters (optional) for easy mobility.
- Certified & Warranty-Backed – cCSAus, CSA Flame, CSA Star, NSF listed and covered by a 1-year parts & labor warranty.
Specifications
| Overall Width | 60.75" / 1543 mm |
|---|---|
| Overall Depth | 42.13" / 1070 mm |
| Cook-Top Height | 37" / 940 mm |
| Height w/ Flue Shelf | 59.5" / 1511 mm |
| Open Burners | 2 × 27,000 BTU non-clog w/ wavy grates |
| Griddle Plate | 48" W × 27" D, 1" polished steel (right side) |
| Oven Type | Convection, 32,000 BTU, 14"H × 26"W × 24"D cavity, 3 racks / 5 positions |
| Secondary Base | Full stainless cabinet (doors optional, no charge) |
| Total Input | 166,000 BTU/hr (natural gas) |
| Gas Connection | ¾" NPT female, min. inlet 7" W.C. NAT / 11" W.C. LP |
| Electrical | 115 V / 60 Hz / 1-ph, 5.9 A, 6' cord & plug (oven fan & spark) |
| Construction | Stainless front, sides, shelf & cabinet; porcelain oven interior |
| Certifications | cCSAus, CSA Flame, CSA Star, NSF |
| Warranty | 1 year parts & labor (see warranty statement) |
Full warranty details, service agency locator and downloadable manuals are available at southbendnc.com/service-and-parts.
- For optimum performance, install under a properly sized vent hood and connect to a ¾" gas line.
- Limit oversized cookware (12"+ diameter) to the rear burners to prevent excess heat on the front rail.
- This appliance is intended for commercial use only and is not approved for residential installation.
