Southbend (Middleby) 4602AC-3GR Ultimate Gas Ranges
$17,056.00
Unit price
/
Unavailable
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options
Southbend (Middleby) 4602AC-3GR Ultimate Gas Ranges is backordered and will ship as soon as it is back in stock.
Documents
Related Searches
Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.
Southbend (Middleby) 4602AC-3GR Ultimate Gas Ranges
$17,056.00
Unit price
/
Unavailable
Description
Southbend Ultimate 60" Gas Restaurant Range
4 Non-Clog Burners • Wavy Grates • 36" Right Griddle • Convection Oven & Cabinet • 204,000 BTUBuilt for high-volume kitchens that demand versatility, the Southbend Ultimate Series packs open-top cooking, a full-size griddle, and a powerful convection oven into one rugged, 60" footprint.
Key Features
- Four 27,000 BTU non-clog cast-iron burners with standing pilots.
- Exclusive wavy cast-iron grates maximize pan stability and heat transfer.
- 36" right-side, ½" polished steel griddle (manual control) delivering 64,000 BTU.
- Left-side convection oven – 32,000 BTU, thermostat range 175 °F–550 °F, porcelain interior, three chrome racks (five positions) and battery-spark ignition.
- Right-side stainless cabinet base for convenient sheet-pan storage (optional doors at no charge).
- 22 ½" flue riser with heavy-duty integrated shelf for plating or small countertop equipment.
- Front-mounted ¾" manual gas shut-off and factory regulator for quick installation.
- 6" adjustable stainless legs (casters optional).
- All-stainless front, sides & rail; certified cCSAus, CSA Flame, CSA Star & NSF.
Performance at a Glance
| Total Input (Natural Gas) | 204,000 BTU/hr |
|---|---|
| Open Top Burners | 4 × 27,000 BTU non-clog burners |
| Griddle | 36" W × 27" D, ½" plate, 64,000 BTU |
| Oven Type / Output | Convection, 32,000 BTU, battery-spark ignition |
| Oven Interior (W × D × H) | 26" × 24" × 14" (3 racks, 5 rack positions) |
| Cooking Surface Height | 37" |
| Overall Width | 60 ¾" |
| Overall Depth | 42 ⅛" |
| Flue Riser Height | 22 ½" to shelf |
| Gas Connection | ¾" NPT (Natural Gas – 7" W.C. minimum) |
| Electrical (Oven Fan) | 115 V, 1 ph, 5.9 A, 6' cord with 3-prong plug |
What’s in the Box
- Southbend Ultimate 60" Range with factory regulator
- Three convection-oven racks
- 22 ½" flue riser & shelf
- 6" adjustable stainless steel legs
- Owner/installation manual
Popular Accessories (Sold Separately)
- All-swivel or front-locking casters
- Hinged cabinet doors
- 3/4" quick-disconnect gas hose kits (3', 4' or 5')
- Salamander / cheesemelter mounting kits
- Additional oven racks
Important Installation & Use Notes
- Commercial installation under a vented hood is required. Minimum clearance to combustibles: 10" sides & rear (0" to non-combustibles).
- If installing on flooring other than quarry tile, cement, or natural stone, consult Southbend for approved options.
- Cookware over 12" diameter should be used on rear burners only to prevent heat damage to the front rail.
Warranty
One-year limited parts & labor warranty. Full details available at southbendnc.com/service-and-parts.
Features & Specs
Features & Specs
Manufacturer
Southbend (Middleby)
Brand_name
Ultimate
Certifications
NSF, cCSAus, CSA Star, CSA Flame
Height
59.5in
Width
60.75in
Depth
43.6in
Shipping Weight
1075.0lbs
Base
(1) convection oven, (1) cabinet
Top
(4) open burners, (1) 36" griddle
Vent
backriser with hi-shelf
Exterior Finish
stainless steel front & sides
Plate Thickness
.500" = 1/2"
Specifications
Ultimate Restaurant Range, gas, 60", (4) non-clog burners, wavy grates, 36" griddle right, standing pilot, (1) convection oven with battery spark ignition, (1) cabinet base, includes (3) racks, 22-1/2" flue riser with shelf, stainless steel front, sides, shelf & 6" adjustable legs, 204,000 BTU, cCSAus, CSA Flame, CSA Star, NSF
