Southbend (Middleby)  |  Ultimate  |  SKU: 4601DD-4TR

Southbend (Middleby) 4601DD-4TR Ultimate Gas Ranges

$16,340.00
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options
Documents
Cutsheet Owner's manual Middleby financial flyer Warranty sheet
Related Searches
Commercial Gas Ranges Commercial Ranges Gas Ranges Ranges Restaurant Equipment

Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.

Description

Southbend Ultimate 60" Gas Restaurant Range – 2 Burners / 48" Thermostatic Griddle / Double Ovens

236,000 BTU | Natural Gas | cCSAus • CSA Flame • CSA Star • NSF

Give your kitchen the power and versatility it deserves. The Southbend Ultimate Series packs two heavy-duty open burners, a full 48-inch thermostatic griddle, and twin standard ovens into one rugged 60-inch footprint—perfect for high-volume restaurants, hotels, and institutional foodservice operations.

Highlights

  • 2 × 33,000 BTU non-clog cast-iron burners with standing pilots
  • 48" wide, 1"-thick polished steel griddle (right-side) with precise thermostatic control
  • Dual 45,000 BTU standard ovens with battery spark ignition (1 rack included per oven)
  • 22 ½" flue riser with integrated heavy-duty shelf for staging plates & pans
  • Front-mounted manual gas shut-off and factory ¾" regulator
  • Stainless steel front, sides, front rail & drip trays for easy clean-up
  • 6" adjustable stainless legs—level installation on any commercial floor
  • 1-year limited parts & labor warranty backed by Southbend’s nationwide service network

Performance Specs

Overall width 60 ¾" (1543 mm)
Depth (incl. rail) 34" (864 mm)
Cooking surface height 37" (940 mm)
Open burners 2 × 33,000 BTU (66,000 BTU total)
Griddle section 48" W × 27" D, 1" steel plate, thermostatic, 160,000 BTU
Ovens (2) Standard, 45,000 BTU each, 175 °F – 550 °F thermostat
Total input 236,000 BTU/hr
Gas connection ¾" NPT (rear)
Shipping weight Approx. 1,075 lb (488 kg)
Certifications NSF, cCSAus, CSA Flame, CSA Star

What’s in the Box

  • (2) removable cast-iron top grates
  • (2) oven racks (1 per oven)
  • Factory-installed pressure regulator & battery pack
  • Installation & operation manual
Installation note: This appliance is for commercial use only and must be installed under a properly sized, code-compliant vent hood. For non-quarry tile floors, consult Southbend for approved mounting options.

Need flexible payment options? Ask us about Middleby Equipment Financing and turn this purchase into budget-friendly monthly payments.

Features & Specs

Manufacturer

Southbend (Middleby)

Brand_name

Ultimate

Certifications

NSF, cCSAus, CSA Star, CSA Flame

Height

59.5in

Width

60.75in

Depth

34.0in

Shipping Weight

1075.0lbs

Top

(2) open burners, (1) 48" griddle with thermostats

Base

(2) standard ovens

Control Type

thermostatic controls

Plate Thickness

.500" = 1/2"

Vent

backriser with hi-shelf

Exterior Finish

stainless steel front & sides

Specifications

Ultimate Restaurant Range, gas, 60", (2) non-clog burners, standard grates, (1) 48" griddle right, thermostatic controls, standing pilot, (2) standard ovens with battery spark ignition, includes (1) rack per oven, 22-1/2" flue riser with shelf, stainless steel front, sides, shelf & 6" adjustable legs, 236,000 BTU, cCSAus, CSA Flame, CSA Star, NSF
