Southbend (Middleby) 4601DD-2GR Ultimate Gas Ranges
$11,934.00
Unit price
/
Unavailable
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options
Southbend (Middleby) 4601DD-2GR Ultimate Gas Ranges is backordered and will ship as soon as it is back in stock.
Documents
Related Searches
Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.
Southbend (Middleby) 4601DD-2GR Ultimate Gas Ranges
$11,934.00
Unit price
/
Unavailable
Description
Southbend Ultimate 60" Gas Restaurant Range – 6 Burners & 24" Right-Side Griddle
Model 460DD-6GR-R | Two Standard OvensBuilt for serious volume and day-long service, the Ultimate Series packs high-efficiency burners, a versatile griddle and twin full-size ovens into a rugged, all-stainless frame that thrives on the busiest cook lines.
Core Performance
- Six 33,000 BTU lifetime non-clog cast-iron burners with standing pilots for instant lighting.
- One 24" wide, ½" polished steel griddle (right side) for eggs, sandwiches, searing & finishing.
- Two 45,000 BTU standard ovens with battery-spark ignition; each ships with a heavy-duty rack.
- 22 ½" flue riser with integrated storage shelf keeps essentials close and the line organized.
- 4" deep stainless front rail doubles as a landing zone and spill shield.
- Front-mounted master gas shut-off and factory-installed ¾" regulator streamline installation.
Quick-View Specifications
| Overall Width | 60 ⅞" (1543 mm) |
|---|---|
| Overall Depth | 34" (864 mm) |
| Cooking Surface Height | 37" (940 mm) |
| Open Burners | 6 × 33,000 BTU non-clog |
| Griddle Section | 24" right-side, 24,000 BTU, ½" steel plate |
| Oven Bases | 2 × 45,000 BTU standard ovens, 14"H × 26"W × 26 ½"D |
| Total Input | 336,000 BTU/hr (Natural Gas) |
| Gas Connection | ¾" NPT (left rear; moves to opposite side if griddle ordered left) |
| Construction | Stainless steel front, sides, riser shelf & 6" adjustable legs |
| Certifications | cCSAus, CSA Flame, CSA Star, NSF |
| Warranty | 1-year parts & labor, factory-authorized service network |
Ultimate Series Advantages
- One-piece burner casting resists clogs & delivers even flame distribution.
- Full porcelain-enamel oven cavities with coved corners wipe clean quickly.
- Removable extra-deep drip trays keep grease contained and maintenance simple.
- Field convertible for LP gas (conversion kit required, sold separately).
Installation Notice: Professional, licensed installation is mandatory.
Minimum inlet pressure – 7" W.C. Natural / 11" W.C. LP.
Unit must be placed under a ventilating hood and mounted on 6" legs or casters when installed on combustible floors.
Need financing? Competitive equipment-financing options are available through Middleby Financial to keep cash-flow steady while upgrading your line.
Features & Specs
Features & Specs
Manufacturer
Southbend (Middleby)
Brand_name
Ultimate
Certifications
NSF, cCSAus, CSA Star, CSA Flame
Height
59.5in
Width
60.75in
Depth
34.0in
Shipping Weight
1075.0lbs
Vent
backriser with hi-shelf
Base
(2) standard ovens
Top
(6) open burners, (1) 24" griddle
Plate Thickness
.500" = 1/2"
Exterior Finish
stainless steel front & sides
Specifications
Ultimate Restaurant Range, gas, 60", (6) non-clog burners, standard grates, (1) 24" griddle right, standing pilot, (2) standard ovens with battery spark ignition, includes (1) rack per oven, 22-1/2" flue riser with shelf, stainless steel front, sides, shelf & 6" adjustable legs, 336,000 BTU, cCSAus, CSA Flame, CSA Star, NSF
