Southbend (Middleby)  |  Ultimate  |  SKU: 4601AD-3GR

Southbend (Middleby) 4601AD-3GR Ultimate Gas Ranges

$17,405.00
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options
Documents
Cutsheet Owner's manual Middleby financial flyer Warranty sheet
Related Searches
Commercial Gas Ranges Commercial Ranges Gas Ranges Ranges Restaurant Equipment

Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.

Description

Southbend “Ultimate” 60" Gas Restaurant Range

4 Open Burners • 36" Right-Hand Griddle • Standard + Convection Ovens • 273,000 BTU

Bring true all-day versatility to the cookline with Southbend’s flagship Ultimate range. Four powerful non-clog burners, a full-size 36" griddle, and dual oven bases (standard & convection) give chefs the freedom to boil, sear, griddle, bake and roast from one rugged station—all in less than 61" of space.

Why This Range Wins in a Busy Kitchen
  • Four 33,000 BTU patented non-clog cast-iron burners—rear grates handle 14" stock pots.
  • 1/2" polished-steel griddle (36" W) on the right: fast recovery, easy to clean, 64,000 BTU.
  • Two oven styles in one chassis:
    • 45,000 BTU standard oven for high-heat roasting & finishing.
    • 32,000 BTU convection oven with ½-HP fan for even baking; on/off fan switch lets it double as a static oven.
  • Battery-spark ignition on both ovens—no external power needed for lighting.
  • 22½" flue riser with reinforced shelf keeps plates, spices or pans right at hand.
  • 4" stainless front rail, front-mounted gas shut-off and factory regulator for quick line-changeovers.
  • Heavy-gauge stainless front, sides & shelf plus 6" adjustable legs built for years of service.
  • Certified cCSAus, CSA Star & Flame and NSF for gas, safety & sanitation compliance.
Oven Capacities
  • Standard Oven: 14" H × 26" W × 26.5" D (fits full-size sheet pans both ways) – 1 rack, 2 positions.
  • Convection Oven: 14" H × 26" W × 24" D – 3 chrome racks, 5 positions.
  • Thermostat range 175 – 550 °F on both ovens.
Technical Specifications
Total BTU Input 273,000 BTU/hr (Natural Gas)
Open Burners (4) × 33,000 BTU non-clog cast iron
Griddle 36" W × 27" D, 64,000 BTU, 1/2" polished-steel plate, manual controls
Ovens Standard: 45,000 BTU • Convection: 32,000 BTU, ½-HP fan, on/off switch
Exterior Dimensions 60 ¾" W × 42 ⅛" D × 59 ½" H (to shelf) • 37" cook-top height
Cooking Surface 27" deep cast-iron grate deck
Gas Connection ¾" NPT (front regulator & shut-off supplied) • 7" W.C. min. inlet (NAT)
Electrical (convection fan only) 115 V / 60 Hz / 1 Ø, 5.9 A – factory-installed 6' cord & NEMA 5-15 plug
Certifications cCSAus, CSA Flame, CSA Star, NSF
Warranty 1-year parts & labor, on-site service by Southbend Authorized Agency
Commercial installation required: This appliance is made for professional kitchens and must be set up under a properly ventilated hood by qualified personnel.

Need financing? Flexible monthly payment options are available through Middleby Equipment Financing—ask your rep for details.

Features & Specs

Manufacturer

Southbend (Middleby)

Brand_name

Ultimate

Certifications

NSF, cCSAus, CSA Star, CSA Flame

Height

59.5in

Width

60.75in

Depth

43.6in

Shipping Weight

1075.0lbs

Vent

backriser with hi-shelf

Top

(4) open burners, (1) 36" griddle

Exterior Finish

stainless steel front & sides

Base

(1) standard oven, (1) convection oven

Plate Thickness

.500" = 1/2"

Specifications

Ultimate Restaurant Range, gas, 60", (4) non-clog burners, standard grates, (1) 36" griddle right, standing pilot, (1) standard oven with battery spark ignition, (1) convection oven with battery spark ignition, includes (4) racks total, 22-1/2" flue riser with shelf, stainless steel front, sides, shelf & 6" adjustable legs, 273,000 BTU, cCSAus, CSA Flame, CSA Star, NSF
