Southbend (Middleby) 4601AC-4TR Ultimate Gas Ranges
Description
Southbend “Ultimate” 60″ Gas Restaurant Range – 2 Burners / 48″ Thermostatic Griddle / Convection Oven
178,000 BTU • Natural Gas • cCSAus, CSA Flame & Star, NSFCombine the power of live-flame sautéing, the versatility of a full-size griddle, and the consistency of forced-air baking in one rugged, space-saving station. Southbend’s Ultimate Series is built for demanding commercial kitchens that won’t settle for anything less than legendary performance and uptime.
Key Performance Features
- (2) 33,000 BTU lifetime non-clog cast-iron burners with standing pilots & removable drip trays.
- Right-side 48″ griddle – 1″ polished steel plate with 4″ splash, thermostatic control 175-550 °F and 96 kBTU input.
- Left-side 32,000 BTU convection oven with battery-spark ignition, 175-550 °F thermostat, porcelain cavity, (3) racks / 5 positions.
- Stainless cabinet base (door-ready, no-charge) keeps sheet pans & smallwares at arm’s reach.
- 22-½″ flue riser with heavy-duty shelf – perfect for warming plates or holding small utensils.
- Front-mounted manual gas shut-off & factory-installed ¾″ regulator for quick service access.
- 4″ stainless front rail, 6″ adjustable stainless legs, and removable cast-iron grates (rear grate fits a 14″ stock pot).
- Total input: 178,000 BTU/hr (Natural Gas).
Built to Outlast Rush After Rush
- All stainless front, sides & shelf resist dents and make nightly cleanup easy.
- Double-sided porcelain oven liner with coved corners for superior airflow and wipe-clean sanitation.
- Spring-assisted oven door and heavy cast components designed for years of trouble-free service.
- One-year parts & labor warranty backed by Southbend’s nationwide service network.
Specifications
| Cooking width | 60 ³⁄₄″ (1543 mm) |
|---|---|
| Open burners | (2) 33 kBTU cast-iron non-clog |
| Griddle | 48″ W × 24″ D, 1″ plate, thermostatic, 96 kBTU |
| Oven type / capacity | Convection, 32 kBTU; 14″ H × 26″ W × 24″ D |
| Total input | 178,000 BTU/hr (Natural Gas) |
| Gas connection | ¾″ NPT (rear), 7″ W.C. NG supply |
| Electric | 115 V / 60 Hz / 1 Ph, 5.9 A (convection fan – cord & 3-prong plug included) |
| Overall dimensions | 60.75″ W × 34″ D × 59.5″ H (with riser) – 37″ cooking height |
| Certifications | cCSAus, CSA Flame, CSA Star, NSF |
| Warranty | 1-year parts & labor |
Intended for commercial use only. Consult local codes for installation and ventilation requirements. Oversized cookware (12″ Ø+) should be positioned over rear burners only to prevent rail damage.
