Southbend (Middleby) 4601AC-3GR Ultimate Gas Ranges

Southbend “Ultimate” 60" Gas Restaurant Range

Built for chefs who refuse to compromise, the Southbend Ultimate Series delivers 228,000 BTU of balanced, blazing heat in a single 60-inch footprint. From quick sears on the open top to even baking in the convection oven, this range keeps every ticket moving — breakfast, lunch or dinner.

Key Features

• Four (4) lifetime 33,000 BTU non-clog cast-iron burners with standing pilots  – perfect for saucepots up to 14".
• 36" smooth steel griddle (½" plate) on the right side; raised sides hold in grease and prevent spatter.
• Left-hand 32,000 BTU convection oven with battery-spark ignition and a 175 – 550 °F thermostat.
• Includes three chrome racks; five-position side rails let you roast, bake or finish multiple sheet pans at once.
• Right-hand stainless cabinet base for sheet pans, smallwares or dry storage (doors available at no charge).
• 22½" flue riser & shelf—a convenient landing area for plates, spices and utensils.
• Front-mounted manual gas shut-off for the entire range; factory-installed pressure regulator.
• All-stainless front, sides, rail and shelf plus 6" adjustable legs for easy leve­ling and cleaning underneath.
• One-year parts & labor warranty backed by Southbend’s nationwide service network.

Performance at a Glance

Included with Your Range

• (1) Ultimate Series 60" range with factory-installed regulator
• (3) convection oven racks
• Stainless 22½" flue riser with heavy-duty shelf
• 6" stainless adjustable legs (casters optional)
• Owner’s manual & quick-start guide

Warranty & Important Notes

• One-year limited parts & labor warranty (see Southbend terms for details).
• Intended for commercial use only; install under a properly vented hood.
• Use oversized cookware (12" +) on rear burners only to protect front rail components.
• If installing on flooring other than quarry tile, cement or natural stone, contact the factory for approved options.

Need flexible financing? Ask about Middleby Equipment Financing for quick approvals and predictable monthly payments.
