Southbend (Middleby) 4601AA-4TR Ultimate Gas Ranges
$20,775.00
Unit price
/
Unavailable
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options
Southbend (Middleby) 4601AA-4TR Ultimate Gas Ranges is backordered and will ship as soon as it is back in stock.
Documents
Related Searches
Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.
Southbend (Middleby) 4601AA-4TR Ultimate Gas Ranges
$20,775.00
Unit price
/
Unavailable
Description
Southbend Ultimate Series 60" Gas Restaurant Range
2 Non-Clog Burners • 48" Right-Side Thermostatic Griddle • Double Convection OvensBuilt for chefs who refuse to compromise, the Southbend Ultimate 60" Range delivers the fire-power of open burners, the versatility of a full-width griddle and the even baking of twin convection ovens—all in a single, stainless-steel station that saves precious line space while boosting production.
Why You’ll Love It
- 210,000 BTU Total Output handles every rush with ease.
- Two 33,000 BTU non-clog cast-iron burners with standing pilots—perfect for sauté pans and stock pots.
-
48" thermostatic griddle (right)
• 1" polished steel plate for superior heat retention
• 80,000 BTU burner system with precise 175 – 550 °F temperature control. - Dual convection ovens (32,000 BTU each) with battery-spark ignition, porcelain interiors and three chrome racks per cavity.
- Stainless steel durability—front, sides, 4" front rail, 22 ½" flue riser/shelf and 6" adjustable legs.
- Front-mounted manual gas shut-off and factory-installed regulator for quick service access.
- cCSAus, CSA Flame, CSA Star & NSF certified for safety and sanitation.
- Backed by a 1-year limited parts & labor warranty with nationwide service support.
At-a-Glance Specs
| Model | Ultimate 4601AA-T (Natural Gas) |
|---|---|
| Overall width | 60 ¾" (1543 mm) |
| Overall depth | 34" (864 mm) |
| Cooking surface height | 37" (940 mm) |
| Open burners | 2 × 33,000 BTU non-clog cast iron (66,000 BTU) |
| Griddle | 48" right, thermostatic, 1" thick plate – 80,000 BTU |
| Ovens | 2 convection, 32,000 BTU each (64,000 BTU) |
| Total input | 210,000 BTU/hr |
| Oven capacity | 14" H × 26" W × 24" D – fits full-size sheet pans both ways |
| Thermostat range | 175 °F – 550 °F (79 °C – 288 °C) |
| Convection motor | ½ HP, 115 V, 5.9 A, cord & 3-prong plug |
| Gas connection | ¾" NPT (rear); 7" WC NAT inlet pressure |
| Construction | Stainless steel front/sides/rail/shelf, removable cast-iron grates, porcelain oven liners |
| Warranty | 1-year parts & labor (see Southbend warranty terms) |
| Certifications | cCSAus, CSA Flame, CSA Star, NSF |
What’s Included
- (4) removable cast-iron top grates
- (6) stainless 6" adjustable legs
- (2) convection oven racks per cavity (3 total)
- 22 ½" flue riser with heavy-duty integrated shelf
- Factory-installed gas pressure regulator & manual shut-off valve
Installation & Use Notes
• Unit is intended for commercial kitchens only and must be installed under a vented hood.
• If installing on flooring other than quarry tile, cement or natural stone, contact the factory for approved methods.
• Limit oversized cookware (12"+ diameter) to the rear burners to avoid excessive front-rail heat.
• Always conform to local gas, electric and fire codes.
• Unit is intended for commercial kitchens only and must be installed under a vented hood.
• If installing on flooring other than quarry tile, cement or natural stone, contact the factory for approved methods.
• Limit oversized cookware (12"+ diameter) to the rear burners to avoid excessive front-rail heat.
• Always conform to local gas, electric and fire codes.
Need flexible financing? Middleby Equipment Financing can turn this purchase into low monthly payments.
Features & Specs
Features & Specs
Manufacturer
Southbend (Middleby)
Brand_name
Ultimate
Certifications
NSF, cCSAus, CSA Star, CSA Flame
Height
59.5in
Width
60.75in
Depth
43.6in
Shipping Weight
1075.0lbs
Top
(2) open burners, (1) 48" griddle with thermostats
Base
(2) convection ovens
Control Type
thermostatic controls
Plate Thickness
.500" = 1/2"
Vent
backriser with hi-shelf
Exterior Finish
stainless steel front & sides
Specifications
Ultimate Restaurant Range, gas, 60", (2) non-clog burners, standard grates, (1) 48" griddle right, thermostatic controls, standing pilot, (2) convection ovens with battery spark ignition, includes (3) racks per oven, 22-1/2" flue riser with shelf, stainless steel front, sides, shelf & 6" adjustable legs, 210,000 BTU, cCSAus, CSA Flame, CSA Star, NSF
