Southbend Ultimate 48-Inch Gas Restaurant Range with 7 Burners and 2 Space Saver Ovens

335,000 BTU, Stainless Steel, 22.5-Inch Flue Riser with Shelf

Built for busy kitchens, this 48-inch gas range pairs a seven-burner top with two space saver ovens in a rugged stainless steel build.

  • Seven-burner top with a mixed high-output burner layout for flexible cooking.
  • Two space saver ovens add below-the-range capacity without increasing footprint.
  • 335,000 BTU total output supports demanding commercial service.
  • Stainless steel front, sides, and shelf with 6-inch adjustable legs for durability and leveling.
  • Includes a 22.5-inch flue riser with shelf and is NSF/CSA listed for commercial kitchens.

Overall Dimensions:

48.63"W x 34.0"D x 59.5"H

Product Weight:

735.0 lb

Mixed Seven-Burner Layout

Top configuration includes 3 star/sauté burners front right, 2 Pyromax burners rear right, 1 star/sauté burner front left, and 1 non-clog burner rear left.

Standing Pilot Open Burners

Standing pilot ignition keeps the open burners ready for service.

Dual Space Saver Ovens

Two oven bases with battery spark ignition add cooking capacity below the range top; one rack is included per oven.

Porcelain Enamel Oven Interior

Double-sided porcelain enamel cavities with coved corners support easier cleaning and improved airflow.

Stainless Steel Construction

Stainless steel front, sides, and shelf provide a durable commercial finish.

Flue Riser with Shelf

Includes a 22.5-inch flue riser with a heavy-duty shelf for rear storage.

Service-Friendly Design

Front-located manual gas shut-off, factory-installed regulator, removable cast iron grates, and drip trays simplify operation and maintenance.

Adjustable Legs

6-inch stainless steel adjustable legs help with leveling during installation.

Type Restaurant Range
Style Open Burner
Installation Type Floor Model (With Legs)
Material Stainless Steel
Finish Stainless Steel
Interior Finish Porcelain Enamel
BTU 335,000 BTU
Compartments 2
Temperature Range 175°F to 550°F
Cooking Surface Depth 27 Inches
Country of Origin USA
Selling Unit Each
Units Per Case 1
Shipping Width 49 Inches
Shipping Depth 34 Inches
Shipping Height 60 Inches
Shipping Weight 735 lb.

Certifications & Compliance

Certified badge of NSF Certified
NSF Certified
Certified badge of CSA Certified
CSA Certified

Warranty & Protection

1-year limited parts and labor

Documents

PDF Cutsheet PDF Download PDF Owner's manual PDF Download PDF Middleby financial flyer PDF Download PDF Warranty sheet PDF Download

Frequently Asked Questions

The top has 7 open burners: 3 star/sauté burners front right, 2 Pyromax burners rear right, 1 star/sauté burner front left, and 1 non-clog burner rear left.
Yes. It includes 2 space saver ovens with battery spark ignition, and each oven comes with 1 rack.
The ovens are thermostatically controlled from 175°F to 550°F (79°C to 288°C).
Each space saver oven measures 14 inches high x 19.5 inches wide x 26.5 inches deep.
Southbend lists a 1-year limited parts and labor warranty from the date of original purchase.
Yes. Optional items listed include 5-inch and 10-inch flue risers, casters, a 3/4-inch quick disconnect with flexible hose, a hot top plate, and extra oven racks.
