Southbend (Middleby) 4484EE-3GR Ultimate Gas Ranges
Description
Southbend “Ultimate” 48" Gas Restaurant Range with 36" Griddle & Double Space-Saver Ovens
Model 448EE · 220,000 BTU total outputGive your kitchen maximum versatility in a single 48" footprint. Southbend’s Ultimate Series pairs rugged cast-iron burners with a high-production griddle and two powerful ovens, all wrapped in easy-to-clean stainless steel. Built for the daily grind of busy restaurants, this range delivers the performance you need—shift after shift, year after year.
Key Features
- 48⅝" wide Ultimate Series gas range with 37" cooking height
- (1) 33,000 BTU star/sauté burner in front for rapid, even heat
- (1) 33,000 BTU lifetime non-clog burner in rear—handles stock pots up to 14"
- 36" right-side griddle, ½" smooth polished steel plate with raised splash sides
- Two 45,000 BTU space-saver ovens (battery spark ignition) with porcelain interiors; thermostat range 175 °F–550 °F; one rack per oven included
- Front-mounted manual gas shut-off and factory-installed regulator
- 22½" flue riser with heavy-duty shelf—perfect for warming plates and keeping tools handy
- Four removable cast-iron grates; deep drip trays for fast clean-ups
- Stainless steel front, sides, rail & shelf plus 6" adjustable stainless legs
- Standing pilots for burners—no external electricity required
- Certifications: cCSAus, CSA Flame, CSA Star, NSF
- One-year limited parts & labor warranty backed by Southbend’s nationwide service network
Performance & Utility Specs
| Total Input | 220,000 BTU/hr (natural gas) |
|---|---|
| Gas Connection | ¾" NPT, opposite the griddle side |
| Minimum Inlet Pressure | 7" W.C. Natural · 11" W.C. LP |
| Electrical | None (battery spark ignition for ovens) |
| Exterior Dimensions | 48.63" W × 34" D × 59.5" H (to top of flue riser) |
| Cooking Surface | 27" deep; removable drip trays |
| Oven Interior (each) | 19.5" W × 26.5" D × 14" H; porcelain enamel |
| Shipping Weight | ≈ 735 lb |
Perfect For
- Busy diners & breakfast houses needing extra griddle real estate
- Independent restaurants maximizing performance in a 48" line up
- Caterers & commissaries seeking an all-in-one sauté, griddle, and baking station
Looking for a different burner or griddle layout? Ask about additional Southbend Ultimate configurations and factory-fit options.
