Southbend (Middleby) 4484DC-6R Ultimate Gas Ranges
Description
Southbend Ultimate 48" Gas Restaurant Range – Custom 6-Burner Top, Standard Oven & Cabinet Base
Model 448 | 290,000 BTU | CSA • NSFPurpose-built for high-output kitchens, the Southbend Ultimate Series couples rock-solid construction with a powerhouse burner package that lets you sear, sauté, simmer and scorch – all on one range. This 48-inch model ships ready to work with a unique blend of star, Pyromax and non-clog burners, a full-size standard oven and a built-in stainless storage cabinet.
Top Configuration
- Front right: 3 × 33 kBTU cast-iron star/sauté burners for even, edge-to-edge heat.
- Rear right: 2 × 40 kBTU patented Pyromax burners – high-output, three-piece, easy-clean design.
- Front left: 1 × 33 kBTU star/sauté burner.
- Rear left: 1 × 33 kBTU lifetime non-clog burner.
- Four removable cast-iron grate sections accept stock pots up to 14" Ø.
- Standing pilots for open burners plus an easy-reach front master gas shut-off.
Base & Oven
- 45 kBTU standard oven with battery-spark ignition—no external power needed.
- Thermostat range 175 °F – 550 °F; porcelain-enameled cavity (26" W × 26.5" D × 14" H).
- Ships with (1) heavy-duty rack and two-position side rails; fits full-size sheet pans either direction.
- 18" stainless cabinet base for dry storage (field-add doors at no charge).
Construction Highlights
- All-stainless front, sides, 4" front rail and 22-1/2" flue riser with shelf.
- 37" high cooking surface on 6" adjustable stainless legs (casters optional).
- Factory-installed ¾" gas pressure regulator.
- Battery-spark oven ignition + standing pilots for zero-electric top operation.
- 1-year limited parts & labor warranty, supported nationwide by Southbend Authorized Service Agencies.
Performance at a Glance
| Total Input | 290,000 BTU/hr (burners + oven) |
|---|---|
| Burners | 3 × 33 kBTU star • 2 × 40 kBTU Pyromax • 1 × 33 kBTU non-clog |
| Oven | 45 kBTU standard oven, 175 – 550 °F thermostat |
| Cooking Surface | 27" deep cast-iron grates |
| Overall Dimensions | 48 5⁄8" W × 34" D × 59 1⁄2" H (with riser) |
| Gas Connection | ¾" NPT (rear; side depends on top configuration) |
| Ignition | Standing pilot (top) / battery spark (oven) |
| Certifications | CSA, NSF |
Why Choose the Ultimate Series?
- Over 125 years of Southbend engineering—built to thrive in the toughest kitchens.
- One-piece, clog-free cast-iron burners reduce downtime and maintenance.
- Modular design makes future upgrades—doors, casters, extra racks—fast and affordable.
- Ships fully assembled, pressure-tested and ready for hook-up.
Looking for doors, casters or additional oven racks? Ask us about factory-authorized accessories and Middleby equipment financing.
