Southbend (Middleby)  |  Ultimate  |  SKU: 4484DC-3TR

Southbend (Middleby) 4484DC-3TR Ultimate Gas Ranges

$13,798.00
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options
Documents
Cutsheet Middleby financial flyer Owner's manual Warranty sheet
Related Searches
Commercial Gas Ranges Commercial Ranges Gas Ranges Ranges Restaurant Equipment

Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.

Description

Southbend Ultimate 48" Gas Restaurant Range with 36" Thermostatic Griddle & 2-Burner Open Top

Model 448-DC | 175,000 BTU | Natural Gas

Give your kitchen the power and versatility of Southbend’s flagship Ultimate Series. This 48" range teams a precision-controlled 36" griddle with two heavy-duty open burners and a full-size oven—delivering an all-in-one workstation that thrives in the rush.

Key Features

  • 48-5/8" wide heavy-duty frame with a 37" cooking surface height
  • (1) 33,000 BTU star/sauté burner (front) for ultra-even flame distribution
  • (1) 33,000 BTU non-clog burner (rear) – lifetime cast-iron design resists blockage
  • 36" thermostatic griddle, 1" polished steel plate, raised splash on three sides
  • Standard oven, 45,000 BTU, 175–550 °F thermostat, battery spark ignition, porcelain interior
  • Right-side stainless cabinet base for convenient pan & utensil storage
  • 22-1/2" flue riser with integrated warming shelf
  • Stainless steel front, sides, rail & shelf; 6" adjustable stainless legs
  • Front-mounted 3/4" manual gas shut-off & factory regulator
  • NSF, cCSAus, CSA Flame & CSA Star certified; 1-year parts & labor warranty

Performance at a Glance

Total Input 175,000 BTU/hr
Gas Connection 3/4" NPT (Natural Gas, 7" W.C. minimum)
Open Burners 2 – (1) star/sauté front, (1) non-clog rear, 33,000 BTU each
Griddle Section 36" W × 27" D, 64,000 BTU, thermostatic 200–450 °F
Oven Cavity 14" H × 26" W × 26-1/2" D – fits full-size sheet pans either direction
Exterior Dimensions 48-5/8" W × 34" D × 59-1/2" H (to top of riser)
Cook-Top Height 37"
Shipping Weight ≈ 735 lb
Certifications NSF, CSA Flame, CSA Star, cCSAus

What’s Included

  • (1) Cast-iron grate set for open burners
  • (1) Chrome-plated oven rack, two-position guides
  • Battery pack for oven ignition
  • 22-1/2" flue riser shelf
  • 1-year limited parts & labor warranty backed by Southbend’s national service network
Installation Note: This appliance is for commercial use under a properly vented hood. For floors other than quarry tile, cement or natural stone, consult the factory for approved leg or caster options. Limit cookware > 12" in diameter to the rear burner to prevent excess heat on the front rail.

Need a different burner or base configuration? Southbend’s Ultimate Series is fully modular—ask us about custom layouts.

Features & Specs

Manufacturer

Southbend (Middleby)

Brand_name

Ultimate

Certifications

NSF, cCSAus, CSA Star, CSA Flame

Height

59.5in

Width

48.63in

Depth

34.0in

Shipping Weight

735.0lbs

Exterior Finish

stainless steel front & sides

Top

(2) open burners, (1) 36" griddle with thermostats

Vent

backriser with hi-shelf

Base

(1) standard oven, (1) cabinet

Plate Thickness

.500" = 1/2"

Specifications

Ultimate Restaurant Range, gas, 48", (1) star/sauté front, (1) non-clog burners rear, standard grates, 36" griddle right, thermostatic controls, standing pilot, (1) standard oven with battery spark ignition, (1) cabinet base, includes (1) rack, 22-1/2" flue riser with shelf, stainless steel front, sides, shelf & 6" adjustable legs, 175,000 BTU, cCSAus, CSA Flame, CSA Star, NSF
