Southbend (Middleby) 4484DC-2GR Ultimate Gas Ranges
Description
Ultimate™ 48" Gas Restaurant Range
Model 448DC — 2 Star + 2 Non-Clog Burners, 24" Right-Side Griddle, Standard Oven & Cabinet BaseBuilt for chefs who refuse to compromise, the Southbend Ultimate™ Series packs hard-hitting performance into a 48 inch footprint. With 225,000 total BTU, a high-output griddle, and Southbend’s legendary open-top burners, this range delivers the speed, consistency, and durability your kitchen demands.
Top-Line Features
- 2 × 33,000 BTU star/ sauté burners in front for fast, even heat.
- 2 × 33,000 BTU lifetime non-clog burners in rear – perfect for stock pots.
- 24" polished steel griddle (½" thick) on the right side; raised sides contain splatter.
- 45,000 BTU standard oven with snap-action thermostat 175 – 550 °F & battery-spark ignition.
- 18" stainless cabinet base (left) for pans, trays, or sheet-pan storage – optional doors available.
- 22½" flue riser with heavy-duty shelf keeps cookware close at hand.
- All-stainless front, sides, and 4" front rail for a sleek, easy-to-clean exterior.
- Front-mounted main gas shut-off & factory-installed regulator for quick service access.
- 6" stainless adjustable legs (casters optional).
- cCSAus, CSA Flame, CSA Star & NSF certified; 1-year parts & labor warranty.
Included With Your Range
- (4) removable cast-iron top grates (rear grate accepts up to 14" stock pot)
- (2) full-width drip trays beneath open burners
- (1) oven rack with two-position guide
- Battery pack for spark ignition
Specifications
| Exterior width | 48 5⁄8" (1235 mm) |
|---|---|
| Exterior depth | 34" (864 mm) to front rail |
| Cook-top height | 37" (940 mm) |
| Total height w/ flue | 59 ½" (1511 mm) |
| Total BTU | 225,000 BTU/hr (natural or LP – field convertible) |
| Oven interior (WxDxH) | 26" × 26 ½" × 14" |
| Gas connection | ¾" NPT (rear, opposite griddle side) |
| Ignition | Standing pilots (top) & battery spark (oven) |
| Clearances | 0" sides & rear to non-combustible walls; 10" to combustibles |
| Shipping weight | Approx. 735 lb (334 kg) |
| Warranty | 1 year parts & labor (see warranty terms) |
Need flexible payments? Middleby Equipment Financing offers fast credit decisions and fixed monthly plans.
- If installing on flooring other than quarry tile, concrete, or natural stone, consult the factory for approved options.
- Limit oversized (12"+) cookware to the rear burners to avoid heat damage to the front rail.
- This appliance is intended for commercial use only and must be installed under a vented hood in accordance with local codes.
