Description

Southbend Ultimate 48" Gas Restaurant Range

Model 448-EE — 2 Star Burners, 36" Right-Side Griddle, Dual Space-Saver Ovens

Pack maximum versatility into minimum line space. Southbend’s Ultimate Series delivers 220,000 BTU of muscle with the rugged construction, easy clean-up and service-friendly design trusted in the busiest kitchens.

Key Features
  • Two 33,000 BTU cast-iron star/sauté burners with standing pilots for instant flame.
  • 36" griddle (right-side), ½" polished steel plate with raised sides, 64,000 BTU burner system.
  • Two space-saver ovens — each 45,000 BTU, battery spark ignition, thermostat 175-550 °F.
  • Oven cavities fit full 18" × 26" sheet pans front-to-back; porcelain enamel for fast wipe-down.
  • 22½" flue riser with heavy-duty stainless shelf keeps plates, pans and spices within reach.
  • Front-mounted manual gas shut-off plus factory-installed pressure regulator.
  • Stainless front, sides and shelf; 6" adjustable stainless legs standard.
  • 1-year limited parts & labor warranty backed by Southbend’s nationwide service network.
  • Certified cCSAus, CSA Flame, CSA Star and NSF for gas safety & sanitation.
Built for Real-World Kitchens
  • Star burner’s unique port pattern blankets cookware with even, high-intensity heat.
  • Half-inch griddle plate heats fast and recovers quickly during the lunch rush.
  • Vertically stacked ovens free up valuable cook-top real estate.
  • Spring-assisted, counter-balanced doors stand up to years of heavy use.
  • Coved oven corners and double-sided porcelain walls resist corrosion and speed cleaning.
Specifications
Overall width 48.63" / 1235 mm
Overall depth 34" / 864 mm
Cooking surface height 37" / 940 mm
Overall height (w/ riser) 59.5" / 1511 mm
Open burners 2 × 33,000 BTU star burners
Griddle 36" W × 27" D, ½" plate, 64,000 BTU
Ovens 2 space-saver ovens, 45,000 BTU each
Total input 220,000 BTU/hr
Gas connection ¾" NPT rear; 7" W.C. NAT / 11" W.C. LP
Electrical None required — battery spark ignition (included)
Shipping weight ≈ 735 lb / 334 kg
What’s in the Box
  • (2) Nickel-plated oven racks — one per cavity
  • 22.5" flue riser with heavy-duty shelf (factory installed)
  • Battery pack for oven spark ignition
  • User, installation & warranty documentation

Need casters, quick-disconnect hose or a salamander mount? Ask your rep about factory-approved accessories.

Installation note: For non-quarry tile floors, oversized cookware or vent-hood requirements, follow Southbend installation guidelines to maintain warranty coverage.

Features & Specs

Manufacturer

Southbend (Middleby)

Brand_name

Ultimate

Certifications

NSF, cCSAus, CSA Star, CSA Flame

Height

59.5in

Width

48.63in

Depth

34.0in

Shipping Weight

735.0lbs

Plate Thickness

.500" = 1/2"

Exterior Finish

stainless steel front & sides

Base

(2) standard / space saver ovens

Top

(2) open burners, (1) 36" griddle

Vent

backriser with hi-shelf

Specifications

Ultimate Restaurant Range, gas, 48", (2) star/sauté burners with standard grates, standing pilot, 36" griddle right, (2) space saver ovens with battery spark ignition, 22-1/2" flue riser with heavy duty shelf, stainless steel front, sides and shelf, 6" adjustable legs, 220,000 BTU, cCSAus, CSA Flame, CSA Star, NSF
