Southbend (Middleby) 4483AC-3CR Ultimate Gas Ranges
$16,238.00
Unit price
/
Unavailable
Description
Southbend Ultimate 48" Gas Restaurant Range – 2 Star Burners, 36" Charbroiler & Convection Oven
Total Input: 194,000 BTU | CSA & NSF CertifiedGive your cooks everything they need in one tough, space-saving footprint. This Ultimate Series range marries Southbend’s legendary open-top power with a high-output charbroiler and a full-size convection oven, all wrapped in easy-to-clean stainless steel.
Why You’ll Love It
- Dual 33,000 BTU Star/Sauté Burners (front left): cast-iron bowls deliver even flame distribution and lifetime clog-free performance.
- 36" Right-Side Charbroiler (96,000 BTU): removable cast-iron grates produce steakhouse sear marks while a standing pilot keeps it ready on demand.
- Convection Oven Base (32,000 BTU): battery-spark ignition, 175 – 550 °F thermostat, porcelain interior with 5 rack positions & 3 included chrome racks.
- Stainless Cabinet Base: dry storage for sheet pans, smallwares and more—right where you need them.
- 22-1/2" Flue Riser w/ Shelf: keeps plates warm and the workspace organized.
- Front Gas Shut-Off & Factory Regulator: fast service access and precise pressure control.
- Removable Drip Trays & Grates: speed daily cleanup and limit downtime.
- 6" Adjustable Stainless Legs: meet health codes and level the unit on uneven floors.
- 1-year limited parts & labor warranty backed by Southbend’s nationwide service network.
At-a-Glance Specs
| Overall Width | 48 5/8" (1235 mm) |
|---|---|
| Overall Depth | 42 1/8" (1070 mm) |
| Cooking Height | 37" (940 mm) work surface |
| Height w/ Riser | 59 1/2" (1511 mm) |
| Open Burners | 2 × 33,000 BTU cast-iron star |
| Charbroiler | 36" radiant, 96,000 BTU, right side |
| Convection Oven | 32,000 BTU, 3 racks / 5 positions, 14" H × 26" W × 24" D cavity |
| Total Input | 194,000 BTU/hr |
| Gas Connection | 3/4" NPT (rear), 7" W.C. Nat. / 11" W.C. LP |
| Electrical | 115 V, 5.9 A, 60 Hz, 1-ph (convection fan), 6' cord & plug included |
| Construction | Stainless steel front, sides, shelf, riser & legs |
| Certifications | CSA, NSF |
| Shipping Weight | ≈ 735 lb (334 kg) |
| Warranty | 1-year parts & labor |
Cleaning Caution: Never place a sheet pan over the charbroiler grates while burners are on.
Reflected heat can cause permanent damage and is not covered by warranty.
Designed for commercial kitchens only. For full installation & warranty details visit southbendnc.com.
Features & Specs
Features & Specs
Manufacturer
Southbend (Middleby)
Brand_name
Ultimate
Certifications
NSF, CSA
Height
59.5in
Width
48.63in
Depth
44.5in
Shipping Weight
735.0lbs
Exterior Finish
stainless steel front & sides
Top
(2) open burners, (1) 36" charbroiler
Base
(1) convection oven, (1) cabinet
Vent
backriser with hi-shelf
Specifications
Ultimate Restaurant Range, gas, 48", (2) star/sauté burners, standard grates, (1) 36" charbroiler right, standing pilot, (1) convection oven with battery spark ignition, (1) cabinet base, includes (3) racks, 22-1/2" flue riser with shelf, stainless steel front, sides, shelf & 6" adjustable legs, 194,000 BTU, CSA, NSF
