Southbend (Middleby) 4482DC-3TR Ultimate Gas Ranges
Description
Southbend Ultimate 48" Restaurant Range – 2-Burner / 36" Thermostatic Griddle Right
Model 448 Series • 163,000 BTU • cCSAus, CSA Flame & Star, NSFEngineered for busy commercial kitchens that demand uncompromising durability and all–day versatility, the 48" Southbend Ultimate Restaurant Range combines two lifetime-clog-free burners with a spacious thermostatically-controlled 36" griddle, a full-size standard oven and a stainless cabinet base. From breakfast rush to late-night service, this single platform handles it all.
Key Features
- 48-5/8" wide commercial gas range with a 37" high cooking surface
- (2) 27,000 BTU non-clog open burners with lifetime cast-iron bowls
- Wavy cast-iron grates optimize pan stability and heat distribution
- 36" right-hand griddle, 1/2" polished steel plate, thermostatic controls 175 – 550 °F
- 4" deep stainless front rail with front-mounted manual gas shut-off
- Standard oven, 45,000 BTU, battery spark ignition, porcelain interior & 1 rack (2 positions)
- 18" stainless cabinet base left side adds convenient pan storage
- 22-1/2" flue riser with heavy-duty shelf – perfect for plates, spices or utensils
- Stainless steel front, sides, shelf & 6" adjustable legs (casters optional)
- Factory-installed 3/4" regulator & standing pilots on open burners
- 1-year limited parts & labor warranty backed by Southbend’s national service network
Performance Specifications
| Total BTU (Natural Gas) | 163,000 BTU/hr |
|---|---|
| Open Burners | (2) 27,000 BTU non-clog cast-iron |
| Griddle Plate | 36" W × 24" D × 1/2" thick polished steel, thermostatic |
| Oven Capacity | 26" W × 26.5" D × 14" H (full-size sheet pans fit either direction) |
| Oven BTU / Temp Range | 45,000 BTU • 175 – 550 °F |
| Overall Dimensions | 48.63" W × 34" D × 59.5" H (to shelf) |
| Gas Connection | 3/4" NPT, rear (opposite griddle) |
| Clearances (Combustible) | 10" sides & rear • 0" to non-combustible |
| Certifications | cCSAus, CSA Flame, CSA Star, NSF |
| Warranty | 1-Year parts & labor (see details below) |
Included With Your Range
- (1) Oven rack
- Factory pressure regulator
- Battery pack for spark ignition
- Installation & operation manual
Installation Notes
• Minimum supply pressure: 7" W.C. Natural Gas / 11" W.C. LP Gas
• Recommended: install under a ventilated hood and on 6" legs or casters.
• If using a flex-hose, I.D. must be ≥ 3/4" and comply with ANSI Z 21.69.
For full warranty terms visit southbendnc.com/service-and-parts.
