Southbend (Middleby)  |  Ultimate  |  SKU: 4481DC-3TR

Southbend (Middleby) 4481DC-3TR Ultimate Gas Ranges

$13,559.00
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options
Documents
Cutsheet Owner's manual Middleby financial flyer Warranty sheet
Related Searches
Commercial Gas Ranges Commercial Ranges Restaurant Equipment

Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.

Description

Southbend Ultimate 48" Gas Restaurant Range – 2 Burners & 36" Thermostatic Griddle

Model 448 | 175,000 BTU | cCSAus, CSA Flame, CSA Star, NSF

Add power, precision and durability to your cook line with Southbend’s flagship Ultimate Series range. Two clog-free open burners, a full-size 36" griddle and a high-performance oven give chefs the flexibility to sauté, grill and bake — all in a single 48" footprint.

Top Features
  • (2) patented, cast-iron non-clog burners — 33,000 BTU each for fast, even heat.
  • (1) 36" right-side griddle with ½" polished steel plate, raised splash sides and independent thermostatic controls (175 °F–550 °F).
  • Standard oven (45,000 BTU) with battery-spark ignition, porcelain interior and spring-assisted door; includes 1 rack with two positions.
  • 18" stainless steel cabinet base keeps sheet pans and smallwares within arm’s reach.
  • 22 ½" flue riser with heavy-duty plate shelf for warming or staging.
  • Front-located ¾" manual gas shut-off plus factory-installed pressure regulator.
  • Stainless steel front, sides, rail and 6" adjustable legs for superior kitchen-grade durability.
  • One-year parts & labor warranty backed by Southbend’s nationwide service network.
Key Specifications
Overall width 48 5⁄8"  (1235 mm)
Overall depth 34"  (864 mm)
Cooking surface height 37"  (940 mm)
Height to top of flue 59 ½"  (1511 mm)
Top configuration (2) 33 K BTU open burners (left) + 36" thermostatic griddle (right)
Base configuration 26" standard oven (left) + 18" stainless cabinet (right)
Oven interior (W × D × H) 26" × 26 ½" × 14"
Included oven racks 1
Total input 175,000 BTU/hr
Gas connection ¾" NPT (rear; opposite griddle side)
Min. inlet pressure Nat 7" W.C. | LP 11" W.C.
Clearances (non-combustible) 0" sides & rear
Certifications cCSAus, CSA Flame, CSA Star, NSF

Always install under a vented hood and follow local code requirements.

Built to Outlast the Rush
  • 27" deep cooking surface with removable drip trays for quick clean-up.
  • Cast-iron grates support stock pots up to 14" in diameter.
  • Coved porcelain oven corners promote even airflow and easy wipe-down.
  • Compatible with optional salamander or cheese-melter mounts (sold separately).
  • Designed, engineered & assembled in Fuquay-Varina, North Carolina.
Installation note: For floors other than quarry tile, concrete or natural stone, contact Southbend for approved mounting options. Use cookware larger than 12" Ø on the rear burners only to prevent excessive heat at the front rail.

Looking for easy monthly payments? Middleby Equipment Financing can help you get cooking fast. Learn more ›

Features & Specs

Manufacturer

Southbend (Middleby)

Brand_name

Ultimate

Certifications

NSF, cCSAus, CSA Star, CSA Flame

Height

59.5in

Width

48.63in

Depth

34.0in

Shipping Weight

735.0lbs

Exterior Finish

stainless steel front & sides

Top

(2) open burners, (1) 36" griddle with thermostats

Vent

backriser with hi-shelf

Base

(1) standard oven, (1) cabinet

Plate Thickness

.500" = 1/2"

Specifications

Ultimate Restaurant Range, gas, 48", (2) non-clog burners, standard grates, (1) 36" griddle right, thermostatic controls, standing pilot, (1) standard oven with battery spark ignition, (1) cabinet base, includes (1) rack, 22-1/2" flue riser with shelf, stainless steel front, sides, shelf & 6" adjustable legs, 175,000 BTU, cCSAus, CSA Flame, CSA Star, NSF
