Southbend Ultimate 48″ Gas Restaurant Range with 36″ Charbroiler & 2-Burner Top
Custom Model 448 - Charbroiler / Burner / Oven / Cabinet ConfigurationCombine the flame-kissed flavor of a high-output charbroiler with the quick responsiveness of open burners and the reliability of a bakery-depth oven—all in one rugged, 48-inch Ultimate Series range. Built for heavy commercial duty, this Southbend workhorse delivers 207,000 BTU of total cooking power and is backed by a full one-year parts-and-labor warranty.
Key Features
- Total input: 207,000 BTU/hr for rapid recovery during peak service.
- (1) 36″ charbroiler (left) with removable cast-iron grates—perfect for steaks, burgers, seafood and vegetables.
- (2) 33,000 BTU non-clog open burners with heavy cast-iron top grates.
- 45,000 BTU standard oven (175–550 °F) with battery-spark ignition; porcelain interior fits full-size sheet pans both ways.
- 18″ stainless steel cabinet base (right) for dry storage — doors may be added at no charge.
- 22 ½″ flue riser with reinforced shelf keeps plates, spices and tools within easy reach.
- 4″ stainless front rail with front-mounted manual gas shut-off valve.
- Stainless steel front, sides & shelf plus 6″ adjustable legs for stable, sanitary installation.
- Factory-installed gas regulator, standing pilots for tops, CSA & NSF listed.
Performance Specifications
| Overall width | 48 5/8″ |
|---|---|
| Cooking surface depth | 27″ |
| Cooking height | 37″ |
| Open burners | (2) 33,000 BTU non-clog |
| Charbroiler | 36″ cast-iron grate, 96,000 BTU |
| Oven base | Standard gas oven, 45,000 BTU 14″ H × 26″ W × 26.5″ D cavity, 1 rack (2 positions) |
| Cabinet base | 18″ stainless steel, open (doors optional) |
| Total input | 207,000 BTU/hr (natural gas) |
| Gas connection | 3/4″ NPT rear (Connection shifts to right side when charbroiler is on the left.) |
| Certifications | CSA, NSF |
| Warranty | 1-year parts & labor |
Perfect For
- Steakhouses and chophouses that demand authentic char flavor.
- Cafés, diners and food trucks with limited line space.
- Hotels, resorts and catering operations needing maximum menu flexibility.
Popular Upgrades (Factory-Installed)
- Stainless cabinet doors (no additional charge).
- Swivel locking casters for easy mobility.
- Extra oven racks.
- Flame-failure safety system.
- 3 ft, 4 ft or 5 ft quick-disconnect gas hose kit (ANSI Z 21.69 compliant).
Preserve cash flow with affordable monthly payments—apply for Middleby Culinary Finance in minutes.
Overall Dimensions:
48.63"W x 34.0"D x 59.5"HProduct Weight:
735.0 lbCertifications & Compliance
