Southbend (Middleby)  |  Ultimate  |  SKU: 4481AC-3GR

Southbend (Middleby) 4481AC-3GR Ultimate Gas Ranges

$14,991.00
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options
Documents
Cutsheet Middleby financial flyer Owner's manual Warranty sheet
Related Searches
Commercial Gas Ranges Commercial Ranges Restaurant Equipment

Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.

Description

Southbend Ultimate 48″ Gas Restaurant Range – 2 Burners & 36″ Right-Side Griddle

Model 448AC-2B36G | 162,000 BTU

Engineered for the busiest kitchens, the Ultimate Series packs the power of a full cook-line into a single 48″ footprint. Two lifetime non-clog burners, an extra-large 36″ griddle, a high-performance convection oven and a built-in storage cabinet give chefs everything they need to sauté, sear, bake and hold – all from one uncompromising work station.

Why you’ll love it

  • (2) 33,000 BTU cast-iron non-clog open burners with standing pilots for instant ignition.
  • 36″ smooth ½″-thick polished steel griddle (right) with raised sides for superior heat retention & splash control.
  • 32,000 BTU convection oven with battery-spark ignition, porcelain interior, 3 nickel-plated racks & 5 rack positions.
  • 18″ stainless steel cabinet base – perfect for sheet pans, hotel pans or stock-pot storage (doors available at no charge).
  • 22 ½″ flue riser with heavy-duty shelf keeps plates warm and supplies within reach.
  • 4″ stainless front rail plus front-mounted manual shut-off for total range control.
  • All-stainless exterior and 6″ adjustable legs for fast cleanup and easy leveling.
  • Factory-installed ¾″ pressure regulator – just hook up gas, plug in the fan and cook.
  • Natural-gas ready; LP conversion kit available.

Performance & utilities

Total input 162,000 BTU/hr
Open burners (2) × 33,000 BTU non-clog cast-iron grates
Griddle plate 36″ W × 27″ D, ½″ polished steel
Convection oven 32,000 BTU | 175–550 °F thermostat | 14″H × 26″W × 24″D cavity
Electrical (fan) 120 V, 1-phase, 5.9 A, 6′ cord with NEMA 5-15P plug
Gas connection ¾″ NPT female, rear

Dimensions & weight

Overall width 48 ⅝″ / 1235 mm
Overall depth (to handle) 42 ⅛″ / 1070 mm
Cooktop height 37″ / 940 mm
Height to flue shelf 59 ½″ / 1511 mm
Shipping weight ≈ 735 lb / 334 kg

Certifications

  • cCSAus
  • CSA Flame
  • CSA Star
  • NSF

What’s in the box

  • (3) nickel-plated oven racks
  • Factory pressure regulator
  • Operator’s manual
  • 1-year limited parts & labor warranty

Intended for commercial use only – install under a vented hood in accordance with local codes.

Oversized cookware notice: Pots 12″ or larger should be used on the rear grate to avoid overheating the front rail and controls.

Features & Specs

Manufacturer

Southbend (Middleby)

Brand_name

Ultimate

Certifications

NSF, cCSAus, CSA Star, CSA Flame

Height

59.5in

Width

48.63in

Depth

43.6in

Shipping Weight

735.0lbs

Plate Thickness

.500" = 1/2"

Exterior Finish

stainless steel front & sides

Top

(2) open burners, (1) 36" griddle

Base

(1) convection oven, (1) cabinet

Vent

backriser with hi-shelf

Specifications

Ultimate Restaurant Range, gas, 48", (2) non-clog burners, standard grates, (1) 36" griddle right, standing pilot, (1) convection oven with battery spark ignition, (1) cabinet base, includes (3) racks, 22-1/2" flue riser with shelf, stainless steel front, sides, shelf & 6" adjustable legs, 162,000 BTU, cCSAus, CSA Flame, CSA Star, NSF
