Southbend “Ultimate” 36" Gas Restaurant Range – 24" Left-Side Griddle & Convection Oven
Model 436A | 146,000 BTU | Natural or PropaneBuilt for kitchens that refuse to compromise, the Southbend Ultimate Range combines high-output open burners, a full-service griddle, and a bakery-depth convection oven in one rugged 36" footprint. From sauté to sear, roast to bake, this is the all-in-one workhorse your line has been waiting for.
Performance & Construction Highlights
- (1) 33,000 BTU cast-iron Star/Sauté burner (front) for rapid, even heat.
- (1) 33,000 BTU non-clog burner (rear) with standard cast-iron grate.
- 24" x 27" ½" thick steel griddle (left) – manual controls, 48,000 BTU.
- 32,000 BTU convection oven with battery spark ignition & (3) chrome racks.
- Standing pilots for open burners; front-mounted manual gas shut-off.
- 22½" flue riser with heavy-duty storage shelf keeps cookware within reach.
- All-stainless front, sides, shelf & 6" adjustable legs for fast clean-ups and perfect leveling.
- Factory-installed gas regulator & 115 V cord-and-plug for oven blower (5.9 A).
- Certified cCSAus, CSA Flame, CSA Star and NSF for peace-of-mind compliance.
- Backed by a 1-year parts & labor warranty with nationwide Southbend service.
Technical Specifications
| Overall width | 36.5" / 927 mm |
|---|---|
| Overall depth (to flue) | 42.13" / 1,070 mm |
| Overall height (to top of riser) | 59.5" / 1,511 mm |
| Cooking surface height | 37" / 940 mm |
| Total input | 146,000 BTU/hr (Natural) | 108,000 BTU/hr (Propane) |
| Gas connection | ¾" NPT (rear) |
| Electrical (oven blower) | 115 V / 60 Hz / 1 Ø • 5.9 A • 6' cord & NEMA 5-15P |
| Oven interior (WxDxH) | 26" x 24" x 14" (660 × 610 × 356 mm) |
| Rack positions / racks supplied | 5 positions / 3 chrome racks |
| Shipping weight | Approx. 660 lb / 300 kg |
| Clearances* | 0" sides & rear (non-combustible) • 10" combustible |
*Install under a vented hood to meet local code.
Why Choose the Ultimate Range?
- Versatility: Sauté, boil, grill, griddle, roast and bake – all on a single 36" chassis.
- Output: 146K BTU of firepower keeps pace with peak-service demand.
- Durability: Heavy, one-piece cast grates & fully-porcelain oven cavity survive daily abuse.
- Serviceability: Front-mounted components and battery spark ignition minimize downtime.
Included Warranty
1-year limited parts & labor coverage. Service must be performed by a Southbend Authorized Service Agency. Consult the full warranty statement for terms and exclusions.
Fast, fixed-payment financing is available through Middleby Capital – keep your cash flow fluid while you upgrade your line.
For commercial use only. Specs subject to change without notice.
Overall Dimensions:
36.5"W x 43.6"D x 59.5"HProduct Weight:
660.0 lbCertifications & Compliance
