Southbend (middleby)

Southbend (middleby) 4363d-2tl ultimate gas ranges

SKU: 4363D-2TL
$8,779.00
/each
Discontinued
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

Related Searches

New arrivals Southbend (middleby)

Southbend Ultimate 36″ Gas Restaurant Range – 2 Star Burners + 24″ Thermostatic Griddle

Model 436 Series | 159,000 BTU | NSF, cCSAus, CSA Flame/Star

Bring powerhouse performance to a compact 36-inch footprint. The Southbend Ultimate Range combines open-top versatility, a full-width griddle and a bakery-depth oven—all wrapped in a rugged, easy-to-clean stainless chassis.

Key Performance Features
  • 2 × 33,000 BTU cast-iron Star/Sauté burners with lifetime, clog-free ports.
  • Left-hand 24″ griddle, ½″ cold-rolled steel, thermostatically controlled 175–550 °F.
  • 45,000 BTU standard oven (battery spark ignition) fits full-size pans both directions.
  • 22.5″ flue riser with built-in shelf keeps plates & spices right where you need them.
  • 4″ deep stainless front rail plus heavy-duty cast-iron grates—rear grate holds up to a 14″ stock pot.
  • Front-mounted manual gas shut-off and factory pressure regulator for quick service access.
  • Total input: 159,000 BTU (natural gas).
  • Stainless steel front, sides & shelf resist corrosion and wipe clean fast.
  • 6″ adjustable stainless legs for perfect leveling on any cookline.
  • Certified for commercial use: NSF, cCSAus, CSA Flame & Star.
At-a-Glance Specs
Overall width 36.5″ (927 mm)
Depth (to rail) 34″ (864 mm)
Cooking height 37″ (940 mm)
Height w/ riser 59.5″ (1,511 mm)
Open burners 2 × Star/Sauté, 33,000 BTU ea.
Griddle plate 24″ W × 27″ D × ½″ T – thermostatic
Oven interior (H×W×D) 14″ × 26″ × 26.5″
Oven BTU 45,000 BTU
Total input 159,000 BTU
Gas connection ¾″ NPT female (rear)
Electrical None – battery spark ignition
Warranty 1-year parts & labor
What’s in the Box
  • (1) Oven rack (two-position rails)
  • 22.5″ stainless flue riser & shelf
  • Factory-installed regulator & batteries
  • Installation / operation manual
Popular Add-Ons (Sold Separately)
  • All-swivel locking casters
  • ANSI Z21.69 compliant quick-disconnect hose (3, 4 or 5 ft)
  • Extra oven racks
  • 5″ or 10″ flue risers
  • Rear step-up burners or hot-top plates
Installation Note: For safe operation, install under a vented hood and supply natural gas at 7″ W.C. Six-inch legs or casters are required on combustible floors. Follow all local codes.

Need flexible financing? Middleby Equipment Financing offers fast approvals and fixed monthly payments—apply online here.

Overall Dimensions:

36.5"W x 34.0"D x 59.5"H

Product Weight:

660.0 lb
Manufacturer Southbend (Middleby)
Brand name Ultimate
Certifications ["NSF", "cCSAus", "CSA Star", "CSA Flame"]
Height 59.5in
Width 36.5in
Depth 34.0in
Shipping Weight 660.0lbs
Plate Thickness .500" = 1/2"
Vent backriser with hi-shelf
Exterior Finish stainless steel front & sides
Base (1) standard oven
Top (2) open burners, (1) 24" griddle with thermostats
Specifications Ultimate Restaurant Range, gas, 36", (2) star/sauté burners, standard grates, (1) 24" griddle left, thermostatic controls, standing pilot, (1) standard oven with battery spark ignition, includes (1) rack, 22-1/2" flue riser with shelf, stainless steel front, sides, shelf & 6" adjustable legs, 159,000 BTU, cCSAus, CSA Flame, CSA Star, NSF

Certifications & Compliance

Certified badge of NSF Certified
NSF Certified
Certified badge of CSA Certified
CSA Certified

Documents

PDF Cutsheet PDF Download PDF Middleby financial flyer PDF Download PDF Owner's manual PDF Download PDF Warranty sheet PDF Download
