Southbend (Middleby)  |  Ultimate  |  SKU: 4363C-1G

Southbend (Middleby) 4363C-1G Ultimate Gas Ranges

$6,788.00
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options
Documents
Cutsheet Middleby financial flyer Owner's manual Warranty sheet
Related Searches
Commercial Gas Ranges Commercial Ranges Restaurant Equipment

Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.

Description

Southbend Ultimate 36" Gas Restaurant Range

4 Star Burners • 12" Left-Side Griddle • Cabinet Base

Built for chefs who demand serious heat and bullet-proof durability, the Southbend Ultimate 36" range delivers 150,000 BTU of one-touch firepower in a compact footprint. Four high-performance star burners handle your sauté, stock-pot, and sauce duties while a 12" steel griddle knocks out everything from breakfast essentials to finishing touches—all above a roomy cabinet base that keeps sheet pans and hotel pans within arm’s reach.

Key features

  • 150,000 BTU total output:
    • (4) 33,000 BTU cast-iron star/saute burners with standing pilots
    • 12" x 27" manual griddle, 18,000 BTU, ½" cold-rolled steel plate
  • 27" deep cook surface with six removable cast-iron grates—rear positions accept up to 14" stock pots
  • 22.5" flue riser with heavy-duty shelf for spices, pans, and finishing plates
  • Stainless steel front, sides, 4" front rail, and shelf for unmatched durability & easy cleanup
  • Cabinet base on 6" adjustable stainless legs (optional doors available at no charge)
  • Front-mounted manual gas shut-off and factory-installed pressure regulator
  • cCSAus, CSA Flame, CSA Star & NSF listed for safety and sanitation
  • Backed by Southbend’s 1-year parts & labor warranty

Specifications

Exterior width 36.5 in. / 927 mm
Exterior depth 34 in. / 864 mm
Cooking surface height 37 in. on 6" legs
Total height (with riser) 59.5 in. / 1,511 mm
Burners (4) open-top star burners, cast iron
Griddle 12" W × 27" D, 18,000 BTU, manual control
Total BTU (Natural) 150,000 BTU/hr
Gas connection ¾" NPT (rear), 7" WC Natural / 11" WC LP
Construction Full stainless exterior, cast-iron grates, removable drip tray
Certifications NSF, CSA Flame, CSA Star, cCSAus
Warranty 1 year parts & labor

Star burner advantage

Southbend’s patented six-point star pattern blankets cookware with an even flame for faster boils, higher searing temps, and tighter control at low simmer. The one-piece cast-iron design is clog-resistant and built to last a lifetime.

Perfect for

  • High-volume restaurants & cafés
  • Hotel and resort production kitchens
  • Catering & commissary operations
  • University, corporate, and healthcare dining
Installation note: Unit must stand on supplied 6" legs (or optional casters) when installed on combustible floors. Maintain 10" clearance from combustible walls and install under a properly vented hood per local code.

Looking for a different burner or griddle layout? Ultimate ranges are factory-configurable—contact us for quick quotes and lead times.

Features & Specs

Manufacturer

Southbend (Middleby)

Brand_name

Ultimate

Certifications

NSF, cCSAus, CSA Star, CSA Flame

Height

59.5in

Width

36.5in

Depth

34.0in

Shipping Weight

660.0lbs

Vent

backriser with hi-shelf

Plate Thickness

.500" = 1/2"

Top

(4) open burners, (1) 12" griddle

Exterior Finish

stainless steel front & sides

Base

(1) cabinet

Specifications

Ultimate Restaurant Range, gas, 36", (4) star/sauté burners, standard grates, (1) 12" griddle left, standing pilot, cabinet base, 22-1/2" flue riser with shelf, stainless steel front, sides, shelf & 6" adjustable legs, 150,000 BTU, cCSAus, CSA Flame, CSA Star, NSF
