Southbend (Middleby) 4363A-2GR Ultimate Gas Ranges
Description
Southbend “Ultimate” 36" Gas Restaurant Range
with 24" Right-Side Griddle & Convection Oven
146,000 BTU • 2 Star/Sauté Burners • Model Family 436 Series
Purpose-built for high–volume, all-day cooking, the Southbend Ultimate Range combines a lightning-hot griddle, two powerful star burners, and a full-size convection oven in a single, stainless-steel workhorse. From breakfast rush to dinner service, this 36" unit delivers the versatility, consistency, and durability serious kitchens demand.
Highlights
- 24" x 27" ½" thick cold-rolled steel griddle (right side) – perfect for searing, sautéing, or bulk breakfast production.
- (2) 33,000 BTU cast-iron star/sauté burners with standing pilots for instant lighting and even flame distribution.
- 32,000 BTU convection oven with battery-spark ignition, 175-550 °F thermostat and 3 adjustable racks.
- Industry-leading 146,000 BTU total input in a 36" footprint.
- 22½" flue riser with heavy-duty integrated shelf keeps cookware close at hand.
- Stainless steel front, sides, 4" deep front rail & 6" adjustable legs – rugged, easy-to-clean construction.
- Front-mounted manual gas shut-off and factory-installed ¾" regulator simplify installation & service.
- Certified NSF, CSA Flame & Star, and cCSAus for gas safety & sanitation.
- Backed by a 1-year parts & labor warranty from Southbend.
Cooking Power Breakdown
| Star/Sauté Burners (2 × 33 k) | 66,000 BTU |
|---|---|
| 24" Griddle Plate | 48,000 BTU |
| Convection Oven | 32,000 BTU |
| Total Input | 146,000 BTU |
Convection Oven Features
- Full-porcelain interior (14" H × 26" W × 24" D) with coved corners for fast, thorough cleaning.
- Three wire racks; five position guides fit full-size sheet pans front-to-back or side-to-side.
- 115 V, 5.9 A plug-in cord – no hard-wiring required.
- High-efficiency ½ HP blower motor for even heat circulation.
- On/off fan switch allows the cavity to be used as a standard oven when desired.
Dimensions & Utilities
| Overall Width | 36.5" |
|---|---|
| Overall Depth (incl. handle) | 42.1" |
| Work-surface Height | 37" |
| Height to Top of Flue Riser | 59.5" |
| Gas Connection | ¾" NPT, rear (146 kBTU/h, Natural Gas 7" W.C./LP 11" W.C.) |
| Electrical (oven fan) | 115 V / 60 Hz / 1-phase, 6' cord & NEMA 5-15P plug |
| Shipping Weight | ≈ 660 lb |
Included with Your Range
- (3) Oven racks
- ¾" pressure regulator (factory installed)
- 22½" flue riser shelf
- 6" adjustable stainless legs
- User, installation & warranty manuals
Popular Add-Ons (sold separately)
- Swivel or locking casters
- Quick-disconnect gas hose kits (3 ft, 4 ft, or 5 ft)
- Extra oven racks
- Shelf-mount salamander or cheesemelter
Oversized cookware (12" Ø+) should be kept to the rear burners only to prevent rail damage. See owner’s manual for full care, cleaning and warranty details.
