Ultimate 36" Gas Restaurant Range with 24" Griddle & Convection Oven
Southbend | Middleby — Ultimate SeriesEngineered for high-volume kitchens that refuse to compromise, the Southbend Ultimate 36" range combines two powerful star/sauté burners, a full-size 24" griddle, and a high-performance convection oven in one rock-solid, stainless-steel platform. With a total 146,000 BTU of cooking muscle, this range lets your line sear, sauté, bake and finish faster – shift after shift.
Why you’ll love it
- Multi-station versatility – open burners, griddle and oven in a single 36" footprint.
- Even-heat star burners (2 x 33,000 BTU NAT) deliver superior flame distribution for perfect sautéing.
- 24" left-side griddle with ½" cold-rolled steel plate and 64,000 BTU output knocks out pancakes, burgers & more.
- Convection oven base (32,000 BTU) with battery-spark ignition, 175–550 °F thermostat and 3 chrome racks.
- Built for the long haul – stainless front, sides, shelf and 6" adjustable legs resist daily abuse.
- 22½" flue riser & storage shelf keep pans handy and heat moving up into the hood where it belongs.
- Front-mounted manual gas shut-off plus factory regulator for safe, simple installation.
- Certified cCSAus, CSA Flame, CSA Star & NSF for worry-free code compliance.
Technical specs
| Overall width | 36.5" (927 mm) |
|---|---|
| Overall depth | 42.13" (1,070 mm) |
| Cooking height | 37" (940 mm) |
| Flue height / overall | 59.5" (1,511 mm) with 22.5" riser & shelf |
| Total BTU (natural gas) | 146,000 BTU/hr |
| Open burners | (2) Star/sauté burners @ 33,000 BTU each (standing pilot) |
| Griddle section | 24" wide • ½" plate • 64,000 BTU |
| Oven type | Battery-spark convection • 32,000 BTU • 3 racks • 14"H × 26"W × 24"D cavity |
| Gas connection | ¾" NPT (rear, opposite griddle side) |
| Electrical (oven fan) | 115 V / 60 Hz / 1-ph • 6′ cord & 3-prong plug • 5.9 A |
| Shipping weight | Approx. 660 lb (300 kg) |
| Warranty | 1-year parts & labor (see warranty tab for details) |
What’s in the box
- (3) chrome oven racks
- Factory-installed pressure regulator
- 6" adjustable stainless legs
- Operator’s & installation manual
Upgrade your line today and spread the cost over time — flexible Middleby equipment financing is available. Ask your rep for details.
Oversized cookware (12"+ diameter) should be kept to the rear grates to prevent excess heat on the front rail. Always install under a properly vented hood.
Overall Dimensions:
36.5"W x 43.6"D x 59.5"HProduct Weight:
660.0 lbCertifications & Compliance
