Southbend (Middleby) 4362A-2CR Ultimate Gas Ranges
Description
Southbend Ultimate Series 36" Gas Restaurant Range
2-Burner / 24" Right-Side Charbroiler / Convection Oven Base • 150,000 BTUConsolidate sautéing, charbroiling, and high-performance baking into one tough, 36-inch footprint. The Ultimate Series gives you Southbend’s legendary durability, energy-rich open burners, and an even-heat convection oven—ideal for kitchens where every square inch and every second count.
- Versatile cooktop – two 27 K BTU non-clog open burners (with wavy grates) beside a full 24" charbroiler.
- Charbroiler power – 64 K BTU NAT cast-iron broiler section for steak-house searing and smoky flavor.
- Turbo-flow convection oven – 32 K BTU, 175 °F–550 °F thermostat, battery spark ignition & (3) chrome racks.
- Built to last – stainless steel front, sides, 4" rail, 22.5" flue riser with heavy-duty shelf & 6" adjustable legs.
- Operator-friendly – front-mount manual gas shut-off, removable drip tray, spring-assisted oven door.
- Field-ready – factory regulator included; 3/4" female gas inlet; CSA & NSF listed for commercial use.
- Peace of mind – backed by Southbend’s 1-year parts & labor warranty.
At-a-Glance Specifications
| Model series | Ultimate 436 A (convection base) |
|---|---|
| Overall width | 36.5" (927 mm) |
| Overall depth | 42.1" (1 070 mm) to front rail |
| Work height | 37" cooking surface |
| Cooktop configuration | (2) 27 K BTU open burners with wavy grates & (1) 24" charbroiler, right-side |
| Total BTU input | 150,000 BTU/hr (natural gas) |
| Oven cavity | 14"H × 26"W × 24"D porcelain enamel, (5) rack positions, (3) racks included |
| Oven motor | 1/2 hp, 115 V, 5.9 A cord & plug (convection fan) |
| Gas connection | 3/4" NPT female, min. 7" WC NAT / 11" WC LP |
| Ignition | Standing pilot for top & charbroiler; battery spark for oven |
| Exterior finish | Stainless steel front, sides, shelf & flue riser |
| Certifications | CSA, NSF |
| Warranty | 1-year parts & labor (commercial use) |
Need a quick ship or financing? Ask us about Middleby Capital’s same-day credit approvals and fixed monthly payments.
Install under a properly sized vent hood and on 6" legs or casters when placed on combustible floors. Always keep cookware clear of the front rail to prevent heat damage, and never cover the charbroiler grates with sheet pans while burners are lit.
