Southbend (Middleby) 4244C Ultimate Gas Ranges
Description
Southbend Ultimate 24" Restaurant Range – Split Top, Cabinet Base
Model 424-C | 132,000 BTU Natural GasPower, versatility and rock-solid construction—packed into just 24 inches of line space. The Southbend Ultimate Series split-top range gives chefs the speed of star/sauté burners up front and the durability of lifetime non-clog burners at the rear, all above a convenient stainless cabinet base.
Top Features
- Four open burners (33,000 BTU each)
- (2) Star/Sauté burners in the front for fast, even pan heating
- (2) Lifetime non-clog burners in the rear—ideal for stock pots up to 14"
- Total input: 132,000 BTU/hr (Natural Gas)
- 27"-deep cooking surface with four removable cast-iron grates
- 22-1/2" stainless flue riser with heavy-duty utility shelf
- Front-mounted manual gas shut-off and standing pilots for instant ignition
- Stainless steel front, sides and shelf resist corrosion and wipe clean fast
- 6" adjustable stainless legs for easy leveling (casters optional)
- Factory-installed pressure regulator • 3/4" rear gas connection
- Spacious stainless cabinet base keeps cookware and chemicals close at hand
- CSA & NSF listed for commercial kitchens
Why the Split Burner Layout?
- Sauté, sear and flambé on the front line while stocks or sauces simmer behind.
- Star ports spread flame evenly, reducing hot spots on delicate pans.
- Keeps a full-service menu flowing from a tight 24" footprint.
Technical Specifications
| Exterior width | 24 3⁄8" (619 mm) |
|---|---|
| Exterior depth | 34" (864 mm) |
| Cook-top height | 37" (940 mm) |
| Overall height (with riser) | 59 1⁄2" (1,511 mm) |
| Cooking surface | 27" deep, cast-iron grates (4) |
| Total BTU | 132,000 BTU/hr |
| Burner rating | 33,000 BTU each |
| Gas connection | 3/4" NPT female (rear) |
| Min. inlet pressure | 7" W.C. NG / 11" W.C. LP |
| Base type | Stainless cabinet, center-opening doors (included) |
| Ship weight | ≈ 475 lb (216 kg) |
| Certifications | CSA, NSF |
| Warranty | 1-year limited parts & labor |
Need optional casters, quick-disconnect hose kits or salamander/cheesemelter mounts? Ask our team for factory-approved accessories.
