Southbend (Middleby) 30108SB Platinum Undercounter & Worktop Refrigeration
Southbend (Middleby) 30108SB Platinum Undercounter & Worktop Refrigeration is backordered and will ship as soon as it is back in stock.
Documents
Related Searches
Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.
Southbend (Middleby) 30108SB Platinum Undercounter & Worktop Re...
Description
Southbend Platinum Series 108" Low-Profile Freezer Base – Model 30108SB
Self-Contained • 6 Drawer • 120 VBring frozen storage right to the cookline. The Southbend Platinum Series 30108SB keeps up to twelve hotel pans of product below zero while supporting any Platinum modular cooktop above— all in a low-boy footprint that maximizes productivity and minimizes steps.
Key Features
- Six 26 inch self-closing drawers on stainless roller slides—each drawer holds two 12 × 20 × 4 inch pans (12 pans total, pans sold separately).
- Low-profile cabinet: 32-½ in. deep × 26 in. high, perfect for mounting Platinum Series range tops without adapters.
- All-304 stainless steel exterior & interior with coved corners for effortless wipe-downs.
- Foamed-in-place CFC-free polyurethane insulation delivers industry-leading temperature retention.
- R-404A refrigeration system with thermostatic expansion valve for rapid pull-down after every drawer cycle.
- Powerful 1/2-HP compressor produces 1,955 BTU/h of cooling capacity.
- Digital thermostat & LED readout—factory calibrated for -10 °F to 10 °F holding, user-adjustable.
- Snap-in magnetic gaskets remove for sink-side cleaning and reinstall in seconds.
- 6 in. adjustable stainless steel legs standard; optional locking casters available for mobile kitchens.
- UL & NSF listed for commercial foodservice installations.
Technical Specifications
| Model | 30108SB |
|---|---|
| Configuration | Low freezer base, 6 center-pull drawers |
| Exterior Width | 108 in. (2,743 mm) |
| Depth | 32.5 in. (826 mm) |
| Height | 26 in. (660 mm) incl. 6 in. legs |
| Storage Capacity | 22 cu ft / holds 12 full-size 4 in.-deep hotel pans |
| Refrigerant | R-404A (CFC-free) |
| Cooling Capacity | 1,955 BTU/h |
| Compressor | 1/2 HP, front-mounted |
| Electrical | 120 V / 60 Hz / 1-Ph, 20 A, 6 ft cord & NEMA 5-20P plug |
| Shipping Weight | 960 lb (435 kg) |
| Certifications | UL, NSF |
| Warranty | 1-year parts & labor, commercial use |
Designed for Platinum Cooktops
Drop any Southbend Platinum Series open-burner, griddle, charbroiler or French-top module directly on this freezer base to create an ultra-efficient production line—cold ingredients below, high-heat cooking above.
Factory Options (sold separately)
- Locking caster kit
- Electric condensate evaporator pan
- Cable restraint kit (required when on casters)
