Description

Southbend Platinum Series 84" Low-Height Remote Freezer Base

Model 30084RSB  |  6 Self-Closing Drawers |  UL & NSF Listed

Give your Platinum modular cookline a built-in blast of frozen storage. The Southbend 30084RSB keeps product at temperature right where the action happens—directly beneath your cooking equipment—without adding height or heat to the line.

Why You’ll Love It

  • 84 inch low-profile base supports any Southbend Platinum cook-top module.
  • Remote refrigeration design keeps compressor heat & noise out of the kitchen (condenser not included).
  • Six heavy-duty, self-closing drawers (4 × 18" & 2 × 26") glide on stainless steel rollers.
  • Each drawer holds industry-standard 12" × 20" × 4" pans for fast, organized access (pans sold separately).
  • 304 stainless steel top, front, sides, back, drawers & interior for maximum durability and easy sanitation.
  • Foamed-in-place, CFC-free polyurethane insulation delivers rapid temperature recovery.
  • Magnetic gaskets & coved interior corners meet NSF 7 requirements and simplify cleaning.
  • Digital thermostat for precise control; mullion coils are corrosion-resistant for long life.
  • 6" adjustable stainless steel legs level the unit on uneven floors; optional casters available.

Technical Specifications

Exterior width 84 in  (2134 mm)
Exterior depth 32.5 in  (826 mm)
Exterior height * 26 in  (660 mm) incl. 6" legs
Drawer configuration 4 × 18"  +  2 × 26" self-closing drawers
Pan capacity 8 standard 12" × 20" × 4" hotel pans
Interior volume 19 cu ft (0.54 m³)
Refrigeration R-404A, remote condenser (not included)
Cooling capacity 1955 BTU/hr
Compressor ½ HP
Electrical 120 V / 60 Hz / 1-ph, 10.1 A, 6 ft cord & plug
Certifications UL, NSF
Warranty 1 year parts & labor

* Low-height design aligns seamlessly beneath Platinum Series range tops.

Installation Notes

  • Minimum 2" rear clearance for ventilation.
  • Operate in ambient temperatures between 55 °F – 90 °F.
  • Condensate drain: ½" I.D. vinyl tube with electric evaporator pan (included).
  • Use an insulated base adapter when mounting cook-top sections.
Remote condenser required: The condenser unit ships separately or may be supplied by your refrigeration contractor.

Popular Add-Ons

  • Heavy-duty locking caster kit
  • Cable restraint kit (recommended when unit is on casters)

Need Financing?

Ask us about Middleby Equipment Financing—fast credit decisions, fixed monthly payments, and potential Section 179 tax advantages.

Intended for commercial use only. Specifications subject to change without notice.

Features & Specs

Manufacturer

Southbend (Middleby)

Brand_name

Platinum

Certifications

NSF, UL

Height

26.0in

Width

84.0in

Depth

32.5in

Shipping Weight

735.0lbs

Width

79" - 84" wide

Compressor HP

1/2 HP

Top Finish

stainless steel top

Exterior Finish

all stainless steel exterior

Refrigeration

remote (refrigeration not included)

Drawer Qty

6 drawers

Specifications

Freezer Base, remote, low height, 84", (4) 18" & (2) 26" self-closing drawers, center pull handles, stainless steel exterior & 6" legs, 120v/60/1-ph, 10.1 amps, 1/2 HP, order with Platinum Series modular cook tops, UL, NSF
