Southbend Platinum Series 72-Inch Low-Height Remote Freezer Base with 4 Self-Closing Drawers
Southbend Platinum Series 72-Inch Low-Height Remote Freezer Base with 4 Self-Closing Drawers
Stainless Steel, 120V, 1-Phase, Remote Condenser Not Included
Keep refrigerated ingredients close at hand with a durable 72-inch freezer base built to pair with Platinum Series modular cook tops.
- 72-inch low-height freezer base designed to support Platinum Series modular sectional range tops.
- Remote refrigeration configuration; remote condenser unit is not included.
- Four self-closing drawers with center pull handles and stainless steel rollers.
- Drawers accept standard 12 x 20 x 4-inch pans; pans are not included.
- 304 stainless steel construction throughout with coved interior corners for easier cleaning.
- Adjustable digital thermostat, CFC-free insulation, and corrosion-resistant mullion coils support efficient temperature recovery.
- 120V single-phase operation with a 6-foot grounded power cord.
- Optional casters, caster frame sizes, and a cable restraint kit are available separately.
Overall Dimensions:
72.0"W x 32.5"D x 26.0"HProduct Weight:
637.0 lbRemote Condenser Design
Configured for remote refrigeration; the remote condenser unit is not included.
Four Self-Closing Drawers
Heavy-duty drawers slide on stainless steel rollers and close automatically for convenient access.
Center Pull Handles
Drawer front handles provide a simple, centered grip for quick opening and closing.
Standard Pan Compatibility
Drawers hold standard 12 x 20 x 4-inch pans; pans are not included.
304 Stainless Steel Construction
Top, front, sides, back, drawers, and interior cavity are built from 304 stainless steel for durability and easy cleanup.
CFC-Free Insulation
Foamed-in-place polyurethane insulation helps maintain temperature and improves efficiency.
Adjustable Digital Thermostat
Digital temperature control allows precise adjustment and monitoring.
Coved Interior Corners
Rounded interior corners help simplify cleaning and support sanitary operation.
6-Inch Adjustable Legs
Stainless steel legs provide stable support and height adjustability.
Condensate Management
Includes a 1/2-inch I.D. drain tube and standard electric condensate evaporator pan.
Modular Cooktop Ready
Designed to support Platinum Series modular sectional range tops and can be mounted with an insulated base adapter.
Grounded Power Connection
Operates on 120-volt single-phase AC power and includes a 6-foot cord with a grounded plug.
Certifications & Compliance
Warranty & Protection
1 year parts and labor
