Southbend (Middleby)  |  Platinum  |  SKU: 20108SB

Southbend (Middleby) 20108SB Platinum Undercounter & Worktop Refrigeration

$20,472.00
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options
Documents
Cutsheet Middleby financial flyer Owner's manual Installation & operation Warranty sheet
Related Searches
Commercial Work Tables Equipment Stands Kitchen Equipment Tables Restaurant Equipment

Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.

Description

Southbend Platinum Series 108" Low-Height Refrigerated Base – Model 20108SB

Self-Contained • 6 Drawers • 120 V / 1-Phase

Keep high-volume ingredients at food-safe temperatures right under your Platinum Series cook line. The 108" Southbend 20108SB refrigerated base delivers heavy-duty, low-profile cold storage that maximizes cook-line efficiency without sacrificing valuable kitchen space.

Key Features
  • Six self-closing 26" drawers on stainless-steel roller slides – each drawer fits two 12" × 20" × 4" pans (12-pan total capacity, pans sold separately).
  • Low 26" cabinet height plus 6" adjustable stainless legs – ideal for mounting Platinum Series modular cook tops.
  • All-304 stainless-steel construction (top, front, sides, back, drawers & interior) for unmatched durability and quick sanitation.
  • 1/2 HP self-contained refrigeration system with expansion valve for rapid temperature recovery.
  • CFC-free R-404A refrigerant and foamed-in-place polyurethane insulation for eco-friendly, efficient cooling.
  • Adjustable digital thermostat with easy-read display.
  • Magnetic drawer gaskets provide a tight seal and pop out for tool-free cleaning.
  • Coved interior corners meet NSF 7 standards and wipe clean fast.
  • Coated mullion evaporator coils promote even airflow and resist corrosion.
  • UL & NSF listed for commercial kitchens.
Specifications
Model 20108SB (Platinum Series)
Overall width 108" (2743 mm)
Overall depth 32.5" (826 mm)
Cabinet height 26" (660 mm) + 6" adjustable legs
Number of drawers 6 × 26" wide
Food-pan capacity 12 pans – 12" × 20" × 4"
Cooled volume 22 cu ft (0.62 m³)
Cooling capacity 1955 BTU/hr
Compressor 1/2 HP, self-contained
Refrigerant R-404A (CFC-free)
Electrical 120 V / 60 Hz / 1-ph, 20 A, NEMA 5-20P cord & plug
Shipping weight 960 lb (435 kg)
Compliance UL, NSF 7
Optional Add-Ons
  • Electric condensate evaporator pan
  • Locking swivel casters or caster frame
  • Cable restraint kit (required when unit is on casters)
Important: Maintain at least 2" rear clearance for proper ventilation. Use only beneath insulated equipment or Platinum Series modular range tops.

Warranty: 1 year parts & labor. Commercial use only.

Features & Specs

Manufacturer

Southbend (Middleby)

Brand_name

Platinum

Certifications

NSF, UL

Height

26.0in

Width

108.0in

Depth

32.5in

Shipping Weight

960.0lbs

Compressor HP

1/2 HP

Width

97" - 108" wide

Top Finish

stainless steel top

Exterior Finish

all stainless steel exterior

Drawer Qty

6 drawers

Refrigeration

self-contained, side mounted

Specifications

Refrigerator Base, self-contained, low height, 108", (6) 26" self-closing drawers, center pull handles, stainless steel exterior & 6" legs, 120v/60/1-ph, 20 amps, 1/2 HP, order with Platinum Series modular cook tops, UL, NSF
